Specifications 525
& Front differential and rear differential gear oil
S12AA13
Oil Front differential gear oil Rear differential gear oil
Oil grade
. SUBARU Extra MT * 3 . API classification GL-5 ( 75W-90 )
Oil capacity * 1 1.3 US qt ( 1.2 liters , 1.1 Imp qt ) 0.8 US qt ( 0.8 liters , 0.7 Imp qt ) Remarks * 2
“ Front differential gear oil and rear differential gear oil ” FP493 * 1 : The indicated oil quantity is only a guideline . The necessary quantity for replacement may differ slightly depending on the temperature and other factors . After refilling the gearbox with oil , the oil level should be checked . * 2 : For more details about maintenance and service , refer to the indicated section . * 3 : The vehicle is filled at the factory with this type of oil .
& Fluids
|
S12AA10 |
|
|
Fluid |
Fluid type * 1
|
Fluid capacity * 2
|
Remarks * 3
|
Continuously variable transmission fluid
Brake fluid
Consult your SUBARU dealer .
FMVSS No . 116 , DOT 3 or DOT 4 brake fluid
Models with air-cooled continuously variable transmission fluid cooler : 12.7 US qt ( 12.0 liters , 10.6 Imp qt )* 4 Models without air-cooled continuously variable transmission fluid cooler : 12.3 US qt ( 11.6 liters , 10.2 Imp qt )* 5
“ Continuously variable transmission fluid ” FP493
— “ Brake fluid ” FP493
* 1 : Use one of the indicated types of fluid . * 2 : The indicated fluid quantity is only a guideline . The necessary quantity for replacement may differ slightly depending on the temperature and other factors . * 3 : For more details about maintenance and service , refer to the indicated section . * 4 : Continuously variable transmission type TR690SXXXX ( To check the model number label for the continuously variable transmission type , refer to
“ Vehicle identification ” FP531 .) * 5 : Continuously variable transmission type TR690GXXXX ( To check the model number label for the continuously variable transmission type , refer to
“ Vehicle identification ” FP531 .)
Specifications
– CONTINUED –
