! Gross Axle Weight ( GAW ) and Gross Axle Weight Rating ( GAWR )
S08AL0203
|
prevent a change in weight distribution while driving .
! Tongue load
S08AL0204
|
|
Certification label
GVWR of your vehicle that is given by SUBARU is shown on the certification label located at the bottom of driver ’ s side door pillar of your vehicle .
|
|||
|
Gross Axle Weight
The total weight applied to each axle ( GAW ) must never exceed the Gross Axle Weight Rating ( GAWR ). The front and rear GAWs can be adjusted by relocating passengers and luggage inside the vehicle . The front and rear GAWR of your vehicle that is given by SUBARU are also shown on the certification label located at the bottom of driver ’ s side door pillar .
To check both GVWR and GAWR and to confirm that the total weight and weight distribution are within safe driving limits , you should have your vehicle and trailer weighed at a commercial weighing station .
Be sure that all cargo is firmly secured to
|
Tongue load
Ensure that the trailer tongue load is from 8 to 11 percent of the total trailer weight and does not exceed the maximum value of the following .
. Models with air-cooled continuously variable transmission fluid cooler : 500 lbs ( 227 kg )
. Models without air-cooled continuously variable transmission fluid cooler : 200 lbs ( 91 kg )
|
Driving tips |
|
– CONTINUED – |
