388
BSD / RCTA
– When the vehicle driving two lanes away is driving on the near side of its lane from your vehicle
& BSD / RCTA OFF indicator
S07BM08
! System temporary stops
S07BM0801
stop condition and the indicator will disappear . If the indicator remains displayed for a prolonged time , have the system inspected at a SUBARU dealer .
! System temporary stops due to reduced radar sensitivity
S07BM0802
& BSD / RCTA warning indicator
S07BM04
! System malfunction
S07BM0403
1 BSD / RCTA temporary stop message 2 BSD / RCTA OFF indicator
This display appears when the system is used under the following conditions .
. Extremely high or low temperatures
. When abnormal voltage exists for the vehicle battery
. When the radar sensor is significantly misaligned
Once the above conditions are corrected , the system will recover from the temporary
1 BSD / RCTA temporary stop message due to reduced radar sensitivity
2 BSD / RCTA OFF indicator
This display appears when the detectability of the radar sensors is reduced . Once the condition is corrected , the system will recover from the temporary stop condition and the indicator will disappear . If the indicator remains displayed for a prolonged time , have the system inspected at a SUBARU dealer .
1 BSD / RCTA malfunction message 2 At first , this message will appear 3 Then this message will appear 4 BSD / RCTA warning indicator
This display appears when a malfunction occurs in the system . Contact a SUBARU dealer and have the system inspected .
