202
Center information display ( CID )
about language settings , refer to “ General settings ” FP210 . For details about unit settings , refer to “ Car settings ” FP215 .
. The images displayed in this Owner ’ s Manual are sample images . The actual image may vary depending on the region and vehicle specifications .
& Welcome screen
S03BS02
Welcome screen and Good-bye screen are motion graphic displayed on the combination meter display and center information display upon entering and exiting the vehicle .
When the driver ’ s door is opened and closed , the welcome screen will appear for a short time .
NOTE
. The welcome screen will disappear when the ignition switch is turned to the “ ON ” position while the welcome screen is shown .
. The welcome screen can be turned on or off . For details , refer to “ General settings ” FP210 .
. For a certain period of time after the welcome screen has once appeared , it may not appear again even when the driver ’ s door is opened and closed . This does not indicate a malfunction .
& Good-bye screen
S03BS08
The good-bye screen will be displayed under the following conditions .
. The driver ’ s door is opened after the ignition switch is put in the “ OFF ” position .
. 3 minutes have passed after the ignition switch is put in the “ OFF ” position with the driver ’ s door closed .
. 10 minutes have passed when the hands-free phone is used after the ignition switch is put in the “ OFF ” position .
. The battery voltage is low when the ignition switch is put in the “ OFF ” position .
& Interruption screen
S03BS03
Useful messages , such as reminders , weather information ( if equipped ) and traffic information ( if equipped ) may interrupt the current screen and appear on the display accompanied by a beep . Take the proper action according to the message .
& Touch screen operations
S03BS04
The center information display has a touch screen . Operations are performed by touching the touch screen directly .
! Touch
Quickly touch and release once .
S03BS0401
