Warning and indicator lights 191 |
||||||||||||
|
& Select lever / gear position indicator
S03AE43
|
1 Upshift indicator 2 Downshift indicator 3 Select lever / gear position indicator
This indicator shows the position of the select lever .
When the manual mode is selected , the gear position indicator ( which shows the current gear selection ) and the upshift / downshift indicator light up . Refer to “ Continuously variable transmission ” FP357 .
|
& Turn signal indicator lights
S03AE20
These lights show the operation of the turn signal or lane change signal .
If the indicator lights do not blink or blink rapidly , the turn signal bulb may be burned out . Replace the bulb as soon as possible . Refer to “ Replacing bulbs ” FP511 .
& High beam indicator light
S03AE21
This light shows that the headlights are in the high beam mode .
This indicator light also illuminates when the headlight flasher is operated .
|
& High beam assist indicator light
S03AE83
This light illuminates when the high beam assist function is activated . For details about the high beam assist function , refer to “ High beam assist function ” FP234 .
|
& Automatic headlight beam leveler warning light
S03AE33
This light illuminates when the automatic headlight beam leveler does not operate normally .
If this light illuminates during driving , have your vehicle inspected at your SUBARU dealer .
|
& LED headlight warning light
S03AE76
This light illuminates if the LED headlights malfunction . Have your vehicle inspected at a SUBARU dealer as soon as possible .
|
& Steering Responsive Headlight OFF indicator light
S03AE89
This light illuminates when the Steering Responsive Headlight is turned off . Refer to “ Steering Responsive Headlight ( SRH )” FP238 .
|
