Warning and indicator lights 183 |
|||||||||||||||||
& Auto Vehicle Hold indicator light |
CAUTION
S03AE94
If the Auto Vehicle Hold indicator light does not illuminate even when “ Auto Vehicle Hold ( AVH )” is touched to activate the Auto Vehicle Hold function , the electronic parking brake system may be malfunctioning .
This indicator light illuminates when the Auto Vehicle Hold is activated . This indicator blinks while the vehicle is stopped by the Auto Vehicle Hold function . For details , refer to “ Auto Vehicle Hold function ” FP376 .
& Low fuel warning light S03AE11
The low fuel warning light illuminates when the tank is nearly empty , at approximately 2.6 US gal ( 10.0 liters , 2.2 Imp gal ). It only operates when the ignition switch is in the “ ON ” position .
|
CAUTION |
Promptly put fuel in the tank whenever the low fuel warning light illuminates . Engine misfires as a |
result of an empty tank could cause damage to the engine .
& Door open warning light S03AE12
The warning light illuminates if any door or the rear gate is not fully closed . This function is effective even if the ignition switch is in the “ LOCK ”/“ OFF ” or “ ACC ” position , or the key is removed from the ignition switch .
|
For some models , only the open doors are indicated by the warning lights .
Always make sure this light is not illuminated before you start to drive .
& Engine hood open warning light
S03AE98
The warning light illuminates if the engine hood is not fully closed . This function is effective even if the ignition switch is in the “ LOCK ”/“ OFF ” or “ ACC ” position , or the key is removed from the ignition switch ( models without “ keyless access with push-button start system ”).
|
Always make sure this light is not illuminated before you start to drive . |
& All-Wheel Drive warning light
S03AE13
This light blinks if the vehicle is driven with tires of differing diameters fitted on the wheels or with an excessively low air pressure in any of the tires .
WARNING
If the AWD warning light flashes , promptly park in a safe location then check whether all four tires are the same diameter and whether any of the tires has a puncture or has lost air pressure for some other reason . Continuing to drive with the AWD warning light flashing can lead to powertrain damage .
NOTE
If the temporary spare tire is used , the AWD warning light may flash . Use of the temporary spare tire should therefore be restricted to the minimum time necessary . Replace the temporary spare tire with a conventional tire as soon as possible .
|
Instruments and controls |
|||||||||
– CONTINUED – |
