Warning and indicator lights 175 |
|||||
|
detect passengers under the following circumstances .
– When cushions or child restraint systems , etc ., are used
– When a child or small adult is sitting in the seat
. Observe the following precautions
– Do not apply any strong impact to the rear seat .
– Do not fold the seatback forward when objects are on the seat .
– Do not spill liquid on the rear seat . If liquid is spilled , wipe it off immediately .
– Do not remove or disassemble the rear seat .
NOTE
. The seatbelt warning system of the rear seats detects if any of the seats are occupied by a passenger . Heavy cargo or large pets on the rear seats may result in the activation of the passenger seatbelt warning light and chime . Fastening the rear seatbelt prior to loading cargo or large pets will avoid activating the passenger seatbelt warning light and
|
chime .
. When folding second- or third-row seats , ensure that the seats are empty prior to folding . Items caught between the seat bottom and seatback , when folded , may damage the seat surface or activate the passenger seatbelt warning light and chime .
! Operation
S03AE011501
If passengers in the rear seats do not fasten their seatbelts while the ignition switch is turned to the “ ON ” position , the seatbelt warning lights will illuminate or blink to indicate that their seatbelts are not fastened .
NOTE
. If the rear passenger ’ s seatbelt ( s ) are / is still not fastened while driving , the seatbelt warning system operates as follows according to the vehicle speed . – The warning light will illuminate when driving approximately 4 mph ( 6 km / h ) or less .
– When driving approximately between 4 mph ( 6 km / h ) and 13 mph ( 20 km / h ), if the seatbelts are not fastened for 50 seconds , the seatbelt warning lights will blink
|
and a warning chime will sound . The chime will make a peep sound for 15 seconds , and it then will become louder and continue for 35 seconds . The warning light will blink for 50 seconds , then it will illuminate steadily and the chime will stop .
– When driving more than approximately 13 mph ( 20 km / h ), if seatbelts are not fastened for 35 seconds , the warning lights of the unfastening seatbelts will blink and a chime will sound loudly . If the rear seatbelts are not fastened after 35 seconds , the blinking warning light will illuminate steadily and the chime will stop . The warning lights will continue to illuminate until their seatbelts are fastened .
. The warning light will turn off and the warning chime will stop when the seatbelt is fastened .
|
& SRS airbag system warning light
WARNING
|
S03AE02
If the warning light exhibits any of the following conditions , immedi-
– CONTINUED –
|
Instruments and controls |
