Warning and indicator lights 173 |
||||||||
|
& Seatbelt warning light and chime
S03AE01
Your vehicle is equipped with a seatbelt warning device at the driver ’ s and passenger ’ s seats , as required by current safety standards .
! Driver ’ s and front passenger ’ s seats
S03AE0114
With the ignition switch turned to the “ ON ” position , this device reminds the driver and front passenger to fasten their seatbelts by illuminating the warning lights in the locations indicated in the following illustration and sounding a chime .
Driver ’ s seat
|
Front passenger ’ s seat
! Operation
S03AE011401
When the ignition switch is turned to the “ ON ” position , the driver ’ s and / or front passenger ’ s warning light will illuminate , then it will blink for several seconds . If the seatbelt of the driver ’ s seat is not fastened , the warning chime may make a peep sound .
NOTE
. If the driver ’ s and / or front passenger ’ s seatbelt ( s ) are / is not fastened while driving , the seatbelt warning system operates as follows according to the vehicle speed . – The warning light will illuminate when driving approximately 4 mph ( 6 km / h ) or less .
|
– The warning light will blink , and the warning chime will make a peep sound when driving between approximately 4 mph ( 6 km / h ) and 13 mph ( 20 km / h ). The warning chime will stop when the vehicle stops .
– The warning light will blink , and the warning chime will sound loudly when 15 seconds have elapsed while driving between approximately 4 mph ( 6 km / h ) and 13 mph ( 20 km / h ).
– The warning light will blink , and the warning chime will sound loudly when driving approximately more than 13 mph ( 20 km / h ).
. The warning light will turn off and the warning chime will stop when the seatbelt is fastened .
If there is no passenger on the front passenger ’ s seat , the seatbelt warning system for the front passenger ’ s seat will be deactivated . The front passenger ’ s seatbelt warning system monitors whether or not there is a passenger on the front passenger ’ s seat .
CAUTION
Observe the following precautions .
– CONTINUED –
|
Instruments and controls |
