Meters and gauges 169 |
|||||
& Odometer |
S03AD04 |
& Double trip meter |
S03AD05 |
To reset the trip meter , select either the A trip or B trip meter , then press and hold the TRIP RESET switch . |
|
CAUTION |
|||||
|
1 TRIP RESET switch 2 Combination meter
This meter displays the odometer when the ignition switch is in the “ ON ” position .
The odometer shows the total distance that the vehicle has been driven .
NOTE
If you press the TRIP RESET switch when the ignition switch is in the “ LOCK ”/“ OFF ” or “ ACC ” position , the odometer / trip meter will light up .
The indicators will turn off when :
. The TRIP RESET switch is not operated for approximately 10 seconds .
. The driver ’ s door is opened and then closed .
|
1 TRIP RESET switch 2 Combination meter
This meter displays the two trip meters when the ignition switch is in the “ ON ” position .
The trip meter shows the distance that the vehicle has been driven since you last set it to zero .
The display can be switched as shown in the following sequence by pressing the TRIP RESET switch .
|
To ensure safety , do not attempt to change the function of the indicator during driving , as an accident could result .
NOTE
. If the connection between the combination meter and battery is broken for any reason such as vehicle maintenance or fuse replacement , the data recorded on the trip meter will be lost .
. If you press the TRIP RESET switch when the ignition switch is in the “ LOCK ”/“ OFF ” or “ ACC ” position , the odometer / trip meter will light up . It is possible to switch between the A trip meter and B trip meter indications while the odometer / trip meter is lit up . In addition , it is possible to reset the trip meter by pressing and holding the TRIP RESET switch . The indicators will turn off when : – The TRIP RESET switch is not operated for approximately 10
|
Instruments and controls |
|||||||
– CONTINUED – |
||||||||||
