148
Rear gate
When the indicator on the window switches does not illuminate , the window switch cannot be operated .
& Initialization of power window ( windows with off delay function )
S02AH06
If the one-touch auto up and down function or off delay function does not operate properly , operate each window according to the following procedure in order to initialize the power window system .
1 . Close the door .
2 . Turn the ignition switch to the “ ON ” position .
3 . Open the window completely and then press and hold down the power window switch for approximately 1 second .
4 . Close the window completely and then pull and hold the power window switch for approximately 1 second .
2-9 . Rear gate
CAUTION
S02AJ
When loading and unloading cargo , be careful not to come in contact with the hot engine exhaust gas or the exhaust pipe , because they could burn you .
& Manual rear gate
S02AJ04
The rear gate can be locked and unlocked using any of the following systems .
. Power door locking switch : Refer to “ Locking and unlocking from the inside ” FP138 .
. Keyless access with the push-button start system ( if equipped ): Refer to “ Keyless access with push-button start system ” FP117 .
. Remote keyless entry system : Refer to “ Remote keyless entry system ” FP133 .
. Automatic door locking / unlocking : Refer to “ Automatic door locking / unlocking ” FP139 .
To open :
Rear gate opener button
1 . Unlock the rear gate .
2 . Press and hold the rear gate opener button . The rear gate will open slightly .
3 . Hold the rear gate and lift it up slowly .
NOTE
If the rear gate cannot be opened due to a discharged vehicle battery , a malfunction in the door locking / unlocking system or other causes , the rear gate can be unlocked by manually operating the rear gate lock release lever . For the procedure , refer to “ Rear gate – if the rear gate cannot be opened ” FP466 .
