Lighting
MASTERColour CDM
930 & 942
The medium wattage lighting system that gives superior,
longer-lasting white light for both indoor and outdoor use
MASTERColour CDM 315w/930
MASTERColour CDM 315w/942
Color Code 930 [ CCT of 3000K] Color Code 942 [ CCT of 4200K]
Luminous Flux (Rated) (Min) 33100 lm Luminous Flux (Rated) (Min) 31200 lm
Luminous Flux (Rated) (Nom) 36200 lm Luminous Flux (Rated) (Nom) 34300 lm
Color Designation Warm White (WW) Color Designation Cool White (CW)
Lumen Maintenance 12000 h (Nom) 83 % Lumen Maintenance 12000 h (Nom) 91 %
Lumen Maintenance 10000 h (Nom) 87 % Lumen Maintenance 10000 h (Nom) 93 %
Lumen Maintenance 2000 h (Nom) 98 % Lumen Maintenance 2000 h (Nom) 97 %
Lumen Maintenance 20000 h 80 % Lumen Maintenance 20000 h 80 %
Lumen Maintenance - 40% Life 87 % Lumen Maintenance - 40% Life 95 %
Lumen Maintenance 5000 h (Nom) 89 % Lumen Maintenance 5000 h (Nom) 96 %
Lumen Maintenance - 10% Life 98 % Lumen Maintenance - 10% Life 97 %
Saturated Red 50 Saturated Red 50
Design Mean Lumens 31500 lm Design Mean Lumens 30780 lm
Chromaticity Coordinate X (Nom) 0.429 Chromaticity Coordinate X (Nom) 0.376
Chromaticity Coordinate Y (Nom) 0.398 Chromaticity Coordinate Y (Nom) 0.379
Correlated Color Temperature (Max) - K Correlated Color Temperature (Max) - K
Correlated Color Temperature (Min) - K Correlated Color Temperature (Min) - K
Correlated Color Temperature (Nom) 3090 K Correlated Color Temperature (Nom) 4140 K
Luminous Efficacy (rated) (Min) 105 lm/W Luminous Efficacy (rated) (Min) 99 lm/W
Luminous Efficacy (rated) (Nom) 115 lm/W Luminous Efficacy (rated) (Nom) 109 lm/W
Color Rendering Index (Min) 87 Color Rendering Index (Min) 87
Color Rendering Index (Nom) 90 Color Rendering Index (Nom) 90
930 Spectrum
942 Spectrum
