Stanley Spare Part E-Book | Page 73

STHM5KHV
5kg HEX Demolition Hammer
Item No. Product Number Qty Per Product Description Type Other Info Markets
Guide Price
(Rp)
1 4050303007 1 RUBBER BOOT 15,700
2 49201042 4 SCREW 11,000
3 4050304015 1 TUBE GUIDE 201,700
5 4050303010 1 O RING 11,000
6 4050304017 1 RAM 36,000
8 4050303017 2 O RING 15,700
10 4050304011 1 PISTON 34,400
11 4050304010 1 PIN 11,000
12 4050301608 1 CAP 18,800
13 4050303006 1 O RING 11,000
17 4050304004 1 CRANKSHAFT 67,300
18 49208024 2 LOCK PIN 11,000
19 49207052 1 CIRCLIP 11,000
20 49106017 1 BEARING 36,000
21 4050303011 1 O RING 11,000
22 4050302601 1 GEARCASE 126,700
23 4050303003 1 SEAL 12,500
24 4050310001 1 GEAR 64,200
25 49111003 1 BEARING 21,900
26 4050302602 1 COVER 43,800
27 4050303601 1 COVER DAMPING SET 12,500
28 4050301601 2 CLAMP DAMPING CLAMP 12,500
29 4050308601 2 SPRING DAMPING SPRING 11,000
36 4050304024 1 CYLINDER SA 243,800
40 4030304015 6 BALL 11,000
42 4050304029 1 NUT 23,500
44 4050303012 1 O RING 11,000
45 4050304023 1 RING 15,700
46 49111017 1 BEARING 23,500
47 4050304031 1 WASHER 11,000
49 4240101005 1 WASHER INSULATING 11,000
50 4090104003 1 WASHER 8*15*0.2 11,000
51 49111013 1 BEARING 17,300
52 4050301007 1 BAFFLE FAN 12,500
53 Z60305016 1 FIELD SA B1 175,000
54 4050301605 1 FIELDCASE SA 81,300
55 4050307001 1 BRUSH HOLDER 25,000
56 N769625 1 BRUSH PAIR SA B1 20,400
57 49201045 4 SCREW 12,500
58 49206018 4 SCREW SELF-TAPPING 4*15 11,000
59 4050301607 1 END CAP 23,500
60 4050303602 1 RUBBER SEAL 11,000
61 N474825 1 RATING LABEL B1 11,000
62 49206039 2 SCREW SELF-TAPPING 11,000
63 4050301604 1 SIDE HANDLE 31,300
64 4050304018 1 BASE BRACKET 15,700
65 4050304019 1 COLLET NUT 21,900
66 4050304020 1 HANDLE FRAME KIT 15,700
67 49205005 2 NUT M6 11,000
68 494014 1 CAPACITOR TW 11,000
69 4050301602 1 SWITCH COVER 14,200
70 49206021 3 SCREW TAPPING SCREW 11,000
71 4050301603 1 HANDLE COVER 34,400
72 4050305601 1 SWITCH B1 81,300
73 4240301011 1 CORD CLAMP B1 11,000
74 49303009 1 CORD PROTECTOR 11,000
75 Z49306050 1 CORDSET B1 73,500
76 4050301606 1 SWITCH HANDLE 45,400
77 4050304601 1 PIN 14,200
78 49201604 1 SCREW 12,500
79 4148004004 1 WRENCH SET B1 25,000
80 4050304604 1 ACCESSORY A9
81 4050304603 1 ACCESSORY A9
82 4030301013 1 OILER use to pack Grease B1 11,000
83 4050322601 1 LABEL 11,000
300 N602553 1 ARMATURE SA B1 376,700
301 4050350003 1 GUIDE SA 481,300
500 4050331001 1 HANDLE SIDE SA 65,700
501 4050331004 1 CONNECTING ROD 54,800
800 901194 1 GREASE 2KG packaging 1,234,400
801 901188 1 GREASE VP870 1kg 3,750,000
802 901192 1 GREASE LP201 SPECS:0.2KG 134,400
861 4050312601 1 KITBOX 228,200
