WRENCHES
OFFSET DOUBLE RING END WRENCH
DEEP IMPACT SOCKET WITH TORQUE WRENCH
Anti Slip
EXCEEDS
ANSI
STANDARD
EXCEEDS
ANSI
STANDARD
STANLEY SKU |
DESCRIPTION |
87-066 |
6 mm Slimline Combination Wrench |
87-057 |
7 mm Slimline Combination Wrench |
87-058 |
8 mm Slimline Combination Wrench |
87-069 |
9 mm Slimline Combination Wrench |
87-070 |
10 mm Slimline Combination Wrench |
87-071 |
11 mm Slimline Combination Wrench |
87-072 |
12 mm Slimline Combination Wrench |
87-073 |
13 mm Slimline Combination Wrench |
87-074 |
14 mm Slimline Combination Wrench |
|
STANLEY SKU
STMT73588-8
STMT73590-8
STMT73591-8
STMT73592-8
|
|
|
|
DESCRIPTION
3 / 8” Torque Wrench 10-50nm
1 / 2” Torque Wrench 40-200nm
1 / 2” Torque Wrench 60-340nm
3 / 4” Torque Wrench 150- 750 Nm
|
RANGE
10- 50Nm / 9.2- 38.7 ft-Lbs
40- 200Nm / 33.2- 151.2 ft-Lbs
60- 340Nm / 51.6- 258.1 ft-Lbs
150- 750Nm 110- 550 ft-Lbs
|
INCRE- MENTS
0.5 Nm
1 Nm
2 Nm
2.5 Nm
|
87-075 15 mm Slimline Combination Wrench |
|
|
|
|
87-076 16 mm Slimline Combination Wrench |
|
|
|
|
87-077 17 mm Slimline Combination Wrench 87-078 18 mm Slimline Combination Wrench 87-079 19 mm Slimline Combination Wrench
COMBINATION WRENCH SET
87-080 20 mm Slimline Combination Wrench 87-081 21 mm Slimline Combination Wrench 87-082 22 mm Slimline Combination Wrench 87-083 23 mm Slimline Combination Wrench 87-084 24 mm Slimline Combination Wrench 87-087 27 mm Slimline Combination Wrench 87-090 30 mm Slimline Combination Wrench
87-092 32 mm Slimline Combination Wrench 87-263-22 33 mm Slimline Combination Wrench 87-264-22 34 mm Slimline Combination Wrench
87-266-22 36 mm Slimline Combination Wrench
• Made of Chrome Vanadium Steel
• Both the open ended head and the ring are angled at 15o for optimum accessibility
• Nickel chrome plating protects against corrosion
• Slim pattern
• MaxiDriveTM and anti-slip open ended jaw shape maintains grip on fastener with only slight rotational pressure
• Anti-slip feature
Anti Slip
EXCEEDS
ANSI
STANDARD
STANLEY SKU STMT78097-8 STMT78098-8 STMT78099-8
DESCRIPTION 12pcs Combination Wrench Set, 6-24mm 9pcs Combination Wrench Set, 8-17mm
8pcs Combination Wrench Set, 8-19mm
• All wrenches suit the existing ANSI, ISO & DIN standards
• MAXI-DRIVE™ feature on ring-end distributes the driving force off the corner of fastener to prevent damage
• Matte finishing makes it easier to clean the solvent on the tool than mirror finishing
• Made of Carbon Steel
• Big size marking makes it easy to reach the desired wrench size during working
73
