HYPEREUTECTIC PISTONS
Hypereutectic pistons with anti-friction skirt coating are ideal for street, bracket racers and oval track. They are highly resistant to scuffing and wear. By combining the hypereutectic alloy with the permanent mold process, the piston is strong, lightweight, and thermally-efficient. These pistons run tighter piston-to-wall clearances, improving ring seal and longevity. Use 1.5mm, 1.5mm, 3mm Ring Set.
4.000” BORE 1.425” COMP. HEIGHT /-4CC FLAT TOP
SM4701- SM4704
SM4701 _ 4.020” / 1.425” /-4cc / HYP SM4702 _ 4.030“ / 1.425” /-4cc / HYP SM4703 _ 4.040” / 1.425” /-4cc / HYP SM4704 _ 4.060” / 1.425” /-4cc / HYP
1.100” COMP. HEIGHT /-4CC FLAT TOP * These pistons include oil ring spacers
SM4705 _ 4.000” / 1.100” /-4cc / HYP SM4706 _ 4.020” / 1.100” /-4cc / HYP SM4707 _ 4.030” / 1.100” /-4cc / HYP SM4708 _ 4.040” / 1.100” /-4cc / HYP SM4709 _ 4.060” / 1.100” /-4cc / HYP
FORGED FLAT TOP PISTONS
Made from 4032 aluminum alloy for quieter operation and reduced piston to wall clearance. Up to 20 % lighter than traditional forged pistons that eliminate harmful stress concentrations for superior strength. Specifically designed for naturally aspirated or moderate nitrous applications. Use 1.5mm, 1.5mm, 3mm Ring Set.
4.000” BORE 1.425” COMP. HEIGHT /-4CC FLAT TOP
SM4710 _ 4.000” / 1.425” /-4cc / FGD SM4711 _ 4.020” / 1.425” /-4cc / FGD SM4712 _ 4.030” / 1.425” /-4cc / FGD SM4713 _ 4.040” / 1.425” /-4cc / FGD SM4714 _ 4.060” / 1.425” /-4cc / FGD
SM4710- SM4714
1.100” COMP. HEIGHT /-4CC FLAT TOP * These pistons include oil ring spacers
SM4720 _ 4.000” / 1.100” /-4cc / FGD SM4721 _ 4.020” / 1.100” /-4cc / FGD SM4722 _ 4.030” / 1.100” /-4cc / FGD SM4723 _ 4.040” / 1.100” /-4cc / FGD SM4724 _ 4.060” / 1.100” /-4cc / FGD
4.125” BORE 1.015” COMP. HEIGHT /-16CC FLAT TOP * These pistons include oil ring spacers
SM4750 _ 4.125” / 1.015” /-16cc / FGD SM4751 _ 4.145” / 1.015” /-16cc / FGD SM4752 _ 4.155” / 1.015” /-16cc / FGD SM4753 _ 4.165” / 1.015” /-16cc / FGD SM4754 _ 4.185” / 1.015” /-16cc / FGD
