TECHNICAL INFORMATION

NPT( NATIONAL PIPE THREAD)
THREAD SIZE
THREAD
CLOSEST
PER INCH
AN SIZE
1 / 8” 1 / 4” 3 / 8” 1 / 2” 3 / 4” 1” 1-1 / 4”
27 18 18 14 14 11.5 11.5
AN-4 AN-6 AN-8 AN-10 AN-12 AN-16 AN-20
AN THREAD( JIC) AN NUT( JIC)
THREAD SIZE
-3-4-5-6-8-10-12-16-20
THREAD PER INCH
3 / 8” 7 / 16” 1 / 2” 9 / 16” 3 / 4” 7 / 8” 1 1 / 16” 1 5 / 16” 1 5 / 8”
CLOSEST AN SIZE
24 20 20 18 16 14 12 12 12
MAX TORQUE
8.75 11.5 14.3 16.25 29 35 45 70 85
HEX SIZE
-3-4-6-8-10-12-16-20
B NUT AN SIDE
1 / 2” 9 / 16” 11 / 16 7 / 8” 1” 1 1 / 4” 1 1 / 2” 2”
S NUT HOSE SIDE
23 / 32” 7 / 8” 1 1 / 32” 1 7 / 32” 1 7 / 16” 1 3 / 4” 2 5 / 16”

HOSE APPLICATION GUIDE

NPT( NATIONAL PIPE THREAD)
HOSE SIZE
100 & 450 SERIES *
200 SERIES
400 SERIES *
525 SERIES
APPLICATION
-3-4-5-6-8-10-12-16-20
YES
YES YES YES YES YES YES
YES YES
YES YES
YES YES YES YES YES YES
YES YES YES YES YES YES YES
Brake, gauge lines & oil lines Oil lines, gauge lines and Vacuum lines Fuel and vacuum lines Water, fuel & oil lines Water, fuel & oil lines Water, fuel & oil lines Water, fuel & oil lines Water & oil lines Water
* Not recommended for E85 & exotic fuels

TURBO FITTING GUIDE

WATER OIL FEED OIL DRAIN APPLICATION
PFD732 PFD734
PFD341 PFD675 PFD675
PFD676 PFD676 PFD676
GT25, GT28, GT30 & GT35 GT37, GT40, GT42 & GT45 GT32, GT47, GT55 & GT60
