ALUMINUM TRANSMISSION OIL COOLERS
SINGLE PASS CYLINDRICAL TRANSMISSION COOLERS
Heat sink transmission coolers are engineered to reduce spikes in temperature, common with the tube / fin-style coolers. They have a low-profile design that allows for multiple mounting positions and locations, including frame rail mounting. These units can also be used to help reduce temperatures in any oil applications.
TDS3401 _ |
Trans Oil Cooler 12” |
TDS3402 _ |
Trans Oil Cooler 15” |
TDS3403 _ |
Trans Oil Cooler 18” |
TDS3404 _ |
Trans Oil Cooler 20” |
TDS3405 _ |
Trans Oil Cooler 22” |
TDS3420 _ |
Trans Oil Cooler 10” |
TDS3421 _ |
Trans Oil Cooler 12” |
TDS3422 _ |
Trans Oil Cooler 15” |
TDS3423 _ |
Trans Oil Cooler 18” |
TDS3424 _ |
Trans Oil Cooler 20” |
TDS3425 _ |
Trans Oil Cooler 22” |
* All Oil Coolers available in RE( D) or BLU( E) by adding the Letter D or E to the end of the part number *
FLAT TRANSMISSION OIL COOLERS
TDS transmission oil coolers feature a new tubular design that improves heat transfer dramatically over other designs. It can drop your transmission fluid temperature 20 degrees, and that can double the life of your automatic transmission. You’ ll get longer life and more consistent shifts even while doing heavy-duty towing.
All necessary fittings come included with the kit.
TDS3406 _ |
Flat Trans Oil Cooler 15.5” x 7.5” |
TDS3407 _ |
Flat Trans Oil Cooler 15.5” x 10” |
DUAL PASS TRANSMISSION COOLER AND THERMO FAN KIT
TDS remote fluid coolers combine a high-capacity oil-cooler core with a 10-inch electric fan for maximum cooling in any environment. This superior combination will give you the peace of mind knowing that your fluids will be at their prime operating temperatures. These coolers feature a core with 1 / 2 in. copper tubes and 3 / 4 in. aluminum fins with plastic edge-guard protectors, all with a durable black powdercoat finish.
Each fan is solidly mounted to the cooler core with clear-anodized billet-aluminum brackets to ensure a stable attachment. You can make these coolers even better with the fan thermostats and installation kits that are sold separately.
TDS3408 _ Dual Pass Trans Cooler & Fan Kit
Overall Height( in) |
10.000 in. |
Overall Width( in) |
12.500 in. |
Overall Thickness( in) |
4.000 in. |
Cooler Construction |
Tube and fin |
Cooler Material |
Aluminum |
Fan Quantity |
Single |
Maximum Fan CFM |
650 cfm |
Fan Diameter( in) |
10.000 in. |
Inlet Size |
-6 AN |
Inlet Attachment |
Male threads |
Outlet Size |
-6 AN |
Outlet Attachment |
Male threads |
Number of Cooling Rows |
16 |
Core Height( in) |
10.000 in. |
Core Width( in) |
10.000 in. |
Core Thickness( in) |
3.000 in. |
Cooler Finish |
Black painted |
Quantity |
Sold as a kit. |
