HIGH PERFORMANCE ELECTRIC FUEL PUMPS
ProFD fuel pumps are designed for Street / Strip application. Externally accessible pressure relief valves and repair kits are readily available. Not for use with fuel injection systems.
|
PROFD“ 95”
Flows 95 GPH( free flow) Pressure is pre-set at 7 PSI
Regulator not required for most applications.
PROFD“ 140”
Compatible with alcohol and / or methanol fuels Flows 140 GPH( free flow) Pressure is pre-set at 14 PSI.
|
PROFD“ 110”
Flows 110 GPH( free flow) Pressure is pre-set at 14 PSI
Fuel Pressure regulator is required.
PROFD“ 110 + R”
Flows 110 GPH( free flow) Pressure is pre-set at 7 PSI
Regulator not required for most applications.
|
PFD49-2801 _ PFD49-2802 _ PFD49-2803 _ PFD49-2807 _ |
95 GPH @ 7 PSI Electric Fuel Pump 110 GPH @ 14 PSI Electric Fuel Pump 140 GPH @ 14 PSI Electric Fuel Pump 110 GPH @ 7 PSI With Int. Reg Electric Fuel Pump
PFD49-2802 PFD49-2807
|
THE PROFD“ 400”
The ProFD 400 GPH Electric fuel pump is both gasoline and alcohol compatible. This fuel pump is extremely efficient and quiet. The high volume output makes this a natural choice for racers.
PFD49-2806D _ PFD49-2806E _ PFD49-2806C _
400 GPH Billet Red Electric Fuel Pump 400 GPH Billet Blue Electric Fuel Pump 400 GPH Billet Chrome Electric Fuel Pump
● Billet components for durability
● High output 6-vane pump with hard-coated rotor for extreme racing conditions
● Adjustable 10-25 PSI bypass valve included with three installation options for top performance
● Features a-12 inlet,-10 outlet,-8 bypass valve ports provided for top performance capabilities
EXTERNAL INLINE FUEL PUMP
For fuel injected engines up to 2000HP naturally aspirated and up to 1450HP with forced induction. For carbureted engines up to 2200HP naturaly aspirated and up to 1650HP with forced induction. E85 and alcohol compatible. Flows upto 1000lbs per hour @ 45 PSI and features AN inlets and outlet ports
SPECS: PFD49-2813 PFD49-2815 PFD49-2817
Free Flow Rate: Constant Pressure( psi): Inlet Size: Inlet Quantity: Inlet Attachment: Outlet Size: Outlet Quantity: Outlet Attachment: Supported Naturally Aspirated Motors: Supported On Forced Induction Engines:
450 lbs./ hr 45 psi- 8AN O-ring Single Female threads- 6AN O-ring Single Female threads
700HP 500HP
800 lbs./ hr 45 psi- 12AN O-ring Single Female threads- 10AN O-ring Single Female threads
1600HP 1100HP
1000 lbs./ hr 45 psi- 12AN O-ring Single Female threads- 10AN O-ring Single Female threads
2000HP 1450HP
