370 RECESSED / WPUSZCZANE
SET RAW mini LED recessed
NEW
Dependent on version / Zależna od wersji LED 350mA, integrated WW and NW colour temperatures available
Power / Moc Light source / Źródło światła
Dimming options: DALI, switchDIM Integrated light source included / Zawiera zintegrowane źródło światła Gear included / Zawiera zasilacz LED Installation dimensions / Wymiary montażowe: Dependent on version / Zależne od wersji
44
H- min 110
M
90
AVAILABLE VERSIONS / DOSTĘPNE WERSJE
BV EV PV
FIXTURE STANDARD FINISH OPTIONS / WYKOŃCZENIA STANDARDOWE
580mm 870mm 1150mm 1430mm 1710mm 1990mm
ALU BLACK WHITE
basic version / wersja podstawowa evolution version / wersja evo premium version / wersja premium module( 28cm) 820 lm / module 1500 lm / module 1230 lm / module
30383EV-01
30385EV-01
30387EV-01
30389EV-01
30391EV-01
30383EV-02
30385EV-02
30387EV-02
30389EV-02
30391EV-02
30383EV-03
30385EV-03
30387EV-03
30389EV-03
30391EV-03
Additional finishes, dimming and NW specifications on aquaform. pl / SR1013
CRI > 80 > 80 > 90
30393EV-01 30393EV-02 30393EV-03
51
L
L [ mm ]
M [ mm ]
Power [ W ]
Flux [ lm ]
580 870
575 865
22.8
34.2
2400 3600
1150
1430
1145
1425
45.6
57.0
4800 6000
1710
1705
68.4
7200
1990
1985
79.8
8400
All data applies to WW
FINISHES / WYKOŃCZENIA MATT GLOSS
> 0,2 m various
SET RAW mini FLUO recessed
Dependent on version / Zależna od wersji TL5 G5
Power / Moc Light source / Źródło światła
Lampholder / Oprawka
Dimming options: DALI, switchDIM Light source not included / Nie zawiera źródła światła Electronic ballast included / Wbudowany statecznik elektroniczny Installation dimensions / Wymiary montażowe: Dependent on version / Zależne od wersji
FIXTURE STANDARD FINISH OPTIONS / WYKOŃCZENIA STANDARDOWE Length Power
ALU BLACK
600mm 600mm 900mm 900mm 1200mm 1200mm 1500mm 1500mm 1500mm
14W 24W 21W 39W 28W 54W 35W 49W 80W
Additional finishes and dimming options on aquaform. pl / SR1023
WHITE
30395-01
30395-02
30395-03
30396-01
30396-02
30396-03
30397-01
30397-02
30397-03
30398-01
30398-02
30398-03
30399-01
30399-02
30399-03
30400-01
30400-02
30400-03
30401-01
30401-02
30401-03
30402-01
30402-02
30402-03
30403-01
30403-02
30403-03
44
51
H- min 110
L
M
NEW
90
L [ mm ]
M [ mm ]
Power [ W ]
600 900
595 895
14
21
24
39
1200
1195
28
54
1500
1495
35
49
80
FINISHES / WYKOŃCZENIA MATT GLOSS various
