368 RECESSED / WPUSZCZANE
SET SLEEK LED recessed
Dependent on version / Zależna od wersji LED 350mA, integrated WW and NW colour temperatures available
AVAILABLE VERSIONS / DOSTĘPNE WERSJE
Power / Moc Light source / Źródło światła
Dimming options: DALI, switchDIM Integrated light source included / Zawiera zintegrowane źródło światła Gear included / Zawiera zasilacz LED Installation dimensions / Wymiary montażowe: Dependent on version / Zależne od wersji
module( 28cm)
CRI
175
M
H- min 120
BV EV PV
basic version / wersja podstawowa evolution version / wersja evo premium version / wersja premium
820 lm / module 1500 lm / module 1230 lm / module
> 80 > 80 > 90
L
FIXTURE STANDARD FINISH OPTIONS / WYKOŃCZENIA STANDARDOWE
600mm 890mm 1170mm 1450mm 1730mm 2010mm
ALU BLACK WHITE
30404EV-01
30406EV-01
30408EV-01
30410EV-01
30412EV-01
30404EV-02
30406EV-02
30408EV-02
30410EV-02
30412EV-02
30404EV-03
30406EV-03
30408EV-03
30410EV-03
30412EV-03
Additional finishes, dimming and NW specifications on aquaform. pl / AC0011
30414EV-01 30414EV-02 30414EV-03
198
L [ mm ]
M [ mm ]
Power [ W ]
Flux [ lm ]
600 890
580 870
45.6
68.4
4800 7200
1170
1450
1150
1430
91.2
114
9600 12000
1730
1710
136.8
14400
2010
1990
159.6
16800
All data applies to WW
FINISHES / WYKOŃCZENIA MATT GLOSS
> 0,2 m various
SET SLEEK FLUO recessed
Dependent on version / Zależna od wersji TL5 G5
Power / Moc Light source / Źródło światła
Lampholder / Oprawka
Dimming options: DALI, switchDIM Light source not included / Nie zawiera źródła światła Electronic ballast included / Wbudowany statecznik elektroniczny Installation dimensions / Wymiary montażowe: Dependent on version / Zależne od wersji
FIXTURE STANDARD FINISH OPTIONS / WYKOŃCZENIA STANDARDOWE Length Power
ALU BLACK
600mm 600mm 900mm 900mm 1200mm 1200mm 1500mm 1500mm 1500mm
2x14W 2x24W 2x21W 2x39W 2x28W 2x54W 2x35W 2x49W 2x80W
Additional finishes and dimming options on aquaform. pl / AC0001
WHITE
30348-01
30348-02
30348-03
30349-01
30349-02
30349-03
30350-01
30350-02
30350-03
30351-01
30351-02
30351-03
30353-01
30353-02
30353-03
30354-01
30354-02
30354-03
30355-01
30355-02
30355-03
30356-01
30356-02
30356-03
30357-01
30357-02
30357-03
175
198
M
H- min 120
L
L [ mm ]
M [ mm ]
Power [ W ]
600
580
2x14
2x24
900
880
2x21
2x39
1200
1180
2x28
2x54
1500
1480
2x35
2x49
2x80
Gear option multiwatt multiwatt multiwatt multiwatt
FINISHES / WYKOŃCZENIA MATT GLOSS various
