Skialight Aquaform Lighting Catalogue 2016 | Page 338

326 RECESSED / WPUSZCZANE
SQUARES 111x3 trimless recessed
3x 35-100W( 3x LED 7-20W) AR111, 12V G53
Power / Moc Light source / Źródło światła
Lampholder / Oprawka
Dimming options: Phase-Control Light source not included / Nie zawiera źródła światła Additional gear required / Wymaga dodatkowo transformatora Installation dimensions / Wymiary montażowe: 160mm( W) x 470mm( L) x 100mm( H)
160
H- min 100
470
160 °
160 °
90
FIXTURE STANDARD FINISH OPTIONS / WYKOŃCZENIA STANDARDOWE
470
ALU BLACK WHITE
32013-01 32013-02 32013-03
160
Additional finishes and dimming options on aquaform. pl / 32013
FINISHES / WYKOŃCZENIA MATT GLOSS
2.1 kg
SQUARES 111x3 trimless 230V recessed
3x 50-100W( 3x LED 10-15W) ES111, 230V GU10
Dimming: Phase-Control Light source not included / Nie zawiera źródła światła Transformer not required / Nie wymaga transformatora Installation dimensions / Wymiary montażowe: 160mm( W) x 470mm( L) x 120mm( H)
Power / Moc Light source / Źródło światła
Lampholder / Oprawka
160
H- min 120
470
160 °
160 °
110
FIXTURE STANDARD FINISH OPTIONS / WYKOŃCZENIA STANDARDOWE
470
ALU BLACK WHITE
32014-01 32014-02 32014-03
160
Additional finishes and dimming options on aquaform. pl / 32014
FINISHES / WYKOŃCZENIA MATT GLOSS
2.2 kg
GU10
Skialight Tel 020 3514 4668 Email sales @ skialight. co. uk Web www. skialight. co. uk
