218 SURFACE / NATYNKOWE equilibra 17 DIRECT LED surface
9W LED 230V, integrated WW and NW colour temperatures available
Power / Moc Light source / Źródło światła
10
Integrated light source included / Zawiera zintegrowane źródło światła Gear not required / Nie wymaga zasilacza LED
170
60
AVAILABLE VERSIONS / DOSTĘPNE WERSJE EV evolution version / wersja evo
Power |
Flux |
CRI |
9W |
480lm |
> 80 |
72
FIXTURE STANDARD FINISH OPTIONS / WYKOŃCZENIA STANDARDOWE
ALU BLACK WHITE
Additional finishes, dimming and NW specifications on aquaform. pl / EQ1014
40051EV-01 40051EV-02 40051EV-03
All data applies to WW
FINISHES / WYKOŃCZENIA MATT GLOSS
> 0,2 m
1.1 kg
equilibra DIRECT LED surface
Dependent on version / Zależna od wersji LED 350mA, integrated WW and NW colour temperatures available
Power / Moc Light source / Źródło światła
10
Dimming options: Dependent on version / Zależny od wersji Integrated light source included / Zawiera zintegrowane źródło światła Gear included / Zawiera zasilacz LED
60
AVAILABLE VERSIONS / DOSTĘPNE WERSJE module( 28cm) CRI
BV EV PV basic version / wersja podstawowa evolution version / wersja evo premium version / wersja premium
820 lm / module 1500 lm / module 1230 lm / module
> 80 > 80 > 90
72
L
FIXTURE STANDARD FINISH OPTIONS / WYKOŃCZENIA STANDARDOWE 360mm 640mm 920mm 1200mm 1480mm
ALU BLACK WHITE
40052EV-01 |
40053EV-01 |
40054EV-01 |
40052EV-02 |
40053EV-02 |
40054EV-02 |
40052EV-03 |
40053EV-03 |
40054EV-03 |
Additional finishes, dimming and NW specifications on aquaform. pl / EQ0032
40055EV-01 40055EV-02 40055EV-03
40056EV-01 40056EV-02 40056EV-03
L [ mm ] |
Power [ W ] |
Flux [ lm ] |
360 |
11,4 |
1200 |
640 |
22,8 |
2400 |
920 |
34,2 |
3600 |
1200 |
45,6 |
4800 |
1480 |
57 |
6000 |
All data applies to WW |
FINISHES / WYKOŃCZENIA MATT GLOSS
> 0,2 m various
