BASET LED wall |
|||
Dependent on version / Zależna od wersji LED 350mA, integrated WW and NW colour temperatures available |
Power / Moc Light source / Źródło światła |
46 |
175 |
Dimming options: Phase-Control Integrated light source included / Zawiera zintegrowane źródło światła Gear included / Zawiera zasilacz LED |
FIXTURE STANDARD FINISH OPTIONS / WYKOŃCZENIA STANDARDOWE | |||
360mm |
680mm |
980mm |
|
ALU BLACK WHITE |
25731BV-01
25731BV-02
25731BV-03
|
25732BV-01
25732BV-02
25732BV-03
|
25733BV-01
25733BV-02
25733BV-03
|
Additional finishes, dimming and NW specifications on aquaform. pl / BA0012 | |||
L [ mm ] |
Power [ W ] |
Flux [ lm ] |
360 |
6.3 |
741 |
680 |
12.6 |
1482 |
980 |
18.9 |
2223 |
All data applies to WW | ||
BASET FLUO wall |
|||
21W TL5 G5 |
Power / Moc Light source / Źródło światła
Lampholder / Oprawka
|
46 |
200 |
Light source not included / Nie zawiera źródła światła Electronic ballast included / Wbudowany statecznik elektroniczny |
FIXTURE STANDARD FINISH OPTIONS / WYKOŃCZENIA STANDARDOWE | ||||
Length 980mm |
Power
21W
|
ALU
22721-01
|
BLACK
22721-02
|
WHITE
22721-03
|
Additional finishes and dimming options on aquaform. pl / 22721 | ||||
