SERVOPRO MultiExact 4100
Safe area
A SOPHISTICATED , NEXT-GENERATION MULTI-GAS ANALYZER PROVIDING A HIGHLY ADAPTABLE ANALYSIS SOLUTION
The MultiExact 4100 is a high-performance multi-gas analyzer designed to provide up to four simultaneous gas stream measurements including : O2 ( trace , control , and purity ), CO2 , CO , N2O , CH4 and H2O .
FEATURES AND BENEFITS
Comprehensive solution for industrial and medical gas manufacture and for pharmacopeia applications
Integrated support for the AquaXact 1688 Aluminum Oxide moisture transmitter
Uses ultra-stable , non-depleting digital sensing technologies that help extend maintenance intervals
APPLICATIONS
Product purity on air separation plants Process control on air separation plants
Monitor trace CO2 on scrubbed air inlet to air separation process
Validation of medical O2 , N2 and air
Gas Measures Application
Multiple
Gas Filter Correlation
Paramagnetic
Infrared
Percent Trace ppm
SENSING TECHNOLOGY
Zirconia
Aluminum Oxide
Process Control
Quality
SERVOPRO MultiExact 4200
Safe area
A SOPHISTICATED , NEXT- GENERATION MULTI-GAS ANALYZER PROVIDING A HIGHLY ADAPTABLE ANALYSIS OF FLAMMABLE GAS SAMPLES FOR TRACE CONTAMINANTS IN INDUSTRIAL APPLICATIONS
The MultiExact 4200 is a high-performance multi-gas analyzer designed to provide up to four simultaneous gas stream measurements including : O2 control , and trace CO2 , CO , N2O , and CH4 .
FEATURES AND BENEFITS
Comprehensive solution for flammable gas contaminant monitoring
Advanced digital communications including Ethernet ( Modbus TCP / IP ) and Modbus RS485
Automated calibration / validation routines triggered by internal timer or external triggers
Touchscreen GUI , now with favourite icon page and text over icon display
Uses ultra-stable , non-depleting digital sensing technologies that help extend maintenance intervals
APPLICATIONS
Hydrogen production HyCO plants Syngas production
Gas Measures Application
Multiple
Gas Filter Correlation
Percent
SENSING TECHNOLOGY
Paramagnetic
Process Control
Quality
SERVOPRO 4900 Multigas
Safe area
AN ADVANCED DIGITAL MULTI-GAS CEMS ANALYZER
Specifically designed for Continuous Emissions Monitoring ( CEMS ) of flue gas , the SERVOPRO 4900 Multigas provides up to four simultaneous gas stream measurements . It combines Servomex ’ s leading-edge sensing technologies with a modern digital platform for next-generation performance .
FEATURES AND BENEFITS
A comprehensive solution for CEMS analysis of multiple flue gas components
Low maintenance and cost of ownership
Advanced digital communications including Ethernet ( Modbus TCP / IP ), Modbus RS485 and PROFIBUS
Automated calibration / validation routines triggered by internal timer or external triggers
Touchscreen GUI , now with favourite icon page and text over icon display
APPLICATIONS Utility boilers Chemical incinerators Crematoria Mobile labs
Gas |
Measures |
Application |
Multiple |
Percent Trace ppm |
Emissions |
SENSING TECHNOLOGY |
Gas Filter Correlation |
Infrared |
Paramagnetic |
P13
