sINGle Gas mONItOr
SPECIFICATIONS
INSTRUMENT WARRANTY:
Two-year warranty from the date of shipment.
CASE:
High visibility, impact-resistant composite with radio frequency
interference (RFI) protection.
DIMENSIONS:
86 mm x 58 mm x 19 mm (3.375" x 2.3" x .75")
WEIGhT:
98 g ( 3.5 oz.)
SENSORS:
CO, H 2 S – Electrochemical
MEASURING RANGES:
Carbon Monoxide
Hydrogen Sulfide
The T40 Rattler™ is a low-cost, maintenance-free
single gas monitor designed to protect personnel from
exposure in the most extreme conditions. Despite its
compact size, the T40 Rattler™ includes features usually
found only in larger multi-gas monitors – including a
large, liquid crystal display (LCD), internal vibrating alarm,
audible/visual alarms and simple push-button operation.
The monitor continuously displays ambient CO or
H 2 S readings in PPM and will alert the user when gas
concentrations exceed the preset low or high levels.
Added features include adjustable alarm setpoints,
calibration gas values, and choice of text-only display
selected by the user through a simple, push-button
routine. The T40 Rattler™ also has a peak/hold feature
to show the highest reading during a shift and includes a
calibration. The T40 Rattler™ operates for up to 1,500
hours on a single “AA” battery (included) and is covered
by a two-year warranty from the date of manufacture.
0-999 ppm in 1 ppm increments
0-500 ppm in 1 ppm increments
ALARMS:
Adjustable low and high alarm setpoints
Power Source (Runtime):
Replaceable “AA” alkaline battery (approx. 1,500 hours typical)
TEMPERATURE RANGE:
-20°C to 50°C (-4°F to 122°F) typical
hUMIDITY RANGE:
15 to 95% RH typical
CERTIFICATIONS:
UL and cUL:
Class I, Groups A, B, C, D , T4
CSA:
Ex ia IIC T4
ATEX:
EEx ia IIC T4; Equipment Group and Category II 2G
IECEx:
Ex ia IIC T4
ANZEx:
Ex ia IIC T4
PART NO.
DESCRIPTION
18105247 T40 Rattler – Hydrogen Sulfide (H 2 S)
18105254 T40 Rattler – Carbon Monoxide (CO)
18105874 T40 Nylon Carrying Case
All Rattler T40 Monitors Include: Battery (installed), additional battery,
maintenance tool and instruction manual.
the t40 rattler’s compact design allows it to fit
comfortably in a shirt pocket, a tool belt or on a hard hat.
