SpecificationS*
iNet-compatible Ventis™ MX4 takes your gas detection
program to the next level.
sampling pump for sample draw applications
Detect from one to four gases with a wide range of
sensor options
Gain visibility of the instrument in darker environments
with a tough, “Safety Orange” overmold
Realize true portability with multi-gas protection in
single-gas size
Utilize the diffusion monitor for 20 hours with a
rechargeable lithium-ion extended range battery pack
Discover a better way to do gas detection when
operating the Ventis on iNet ®
Introducing the Ventis MX4 — a compact, multi-gas monitor
available in both aspirated and diffusion versions. Both highly
gas detection needs with ease. It is the ideal instrument for
any other potentially hazardous environment.
This lightweight instrument is available with a bright "safety
orange" overmold providing visibility in darker environments.
An extended range lithium-ion battery pack provides up to
20 hours of continuous monitoring when using the diffusion
version. Best of all, the Ventis is compatible with iNet and our
DS2 Docking Station.
inStrument Warranty:
Two- year warranty, including sensors and battery
case material:
Polycarbonate w/ protective rubber overmold
DimenSionS:
103 mm x 58 mm x 30 mm (4.1” x 2.3” x 1.2”) - Ventis lithium-ion battery
version
172 mm x 67 mm x 66 mm (6.8” x 2.6” x 2.6”) - Ventis with pump
lithium-ion battery version
Weight:
182 g (6.4 oz) - Ventis, lithium-ion battery version
380 g (13.4 oz) - Ventis with Pump, lithium-ion battery version
operating temperature range:
-20°C- 50°C (-4°F-122°F)
operating humiDity range:
15%-95% non-condensing (continuous)
DiSplay/reaDout:
Backlit Liquid Crystal Display (LCD)
poWer Source/run time:
Rechargeable lithium-ion battery pack
(12 hours typical @ 20ºC) - Ventis
Rechargeable extended-range lithium-ion battery pack
(20 hours typical @ 20ºC) - Ventis
(12 hours typical @ 20ºC) - Ventis with pump
Replaceable AAA alkaline battery pack
(8 hours typical @ 20ºC) - Ventis
(4 hours typical @ 20ºC) - Ventis with pump
alarmS:
Ultra-bright LEDs, loud audible alarm (95 dB at 30 cm), and vibrating alarm
Sensors:
Combustible gases/methane - Catalytic Diffusion
O 2 , CO, H 2 S, NO 2 , SO 2 - Electrochemical
meaSuring rangeS:
Combustible Gases:
0-100% LEL in 1% increments
0-5% of vol. in 0.01% increments
Methane (CH 4 ):
0-30% of vol. in 0.1% increments
Oxygen (O 2 ):
Carbon monoxide (CO):
0-1,000 ppm in 1 ppm increments
0-500 ppm in 0.1 ppm increments
Hydrogen sulfide (H 2 S):
0-150 ppm in 0.1 ppm increments
Nitrogen dioxide (NO 2 ):
0-150 ppm in 0.1 ppm increments
Sulfur dioxide (SO 2 ):
certificationS:
UL:
Class I, Division 1, Groups A B C D, T4; Zone 0,
AEx ia IIC T4
Class II, Groups F G (Carbonaceous & Grain dust);
IP66; IP67
ATEX:
Ex ia IIC T4 Ga and Ex ia I Ma;
Equipment Group and Category II 1G and I M1; IP66; IP67
IECEx:
Ex ia IIC T4 Ga; IP66; IP67
CSA:
Class I, Division 1, Groups A B C D, T4; Ex d ia IIC T4
C22.2 No. 152 for %LEL reading only
ANZEx:
Ex ia s Zone 0 I/IIC T4; IP66; IP67
INMETRO: Ex d ia IIC T4 Gb; IP66; IP67
KOSHA:
Ex d ia IIC T4
MSHA:
30 CFR Part 22; Permissible for underground mines;
Li-ion versions only
Permissible for PA Bituminous Underground Mines
PA-DEP:
CHINA EX: Ex ia d IIC T4 Gb
CHINA CMC: Metrology approval
CHINA MA: Approved for underground mines; diffusion (without pump)
standard Alkaline version only
GOST- K: PBExdiaI X / 1ExdiaIICT4 X
PBExdiaI X / 1ExdiaIICT4 X
GOST-R:
* These specifications are based on performance averages and may vary by instrument
