SACOR BUSINESS GROUP-2019 COMPANY CATALOGUE SACOR BUSINESS GROUP 2019 COMPANY CATALOGUE | Page 101

32
reGulatOrs
Regulators provide the proper flow rate for calibrating your Industrial Scientific instrument. Always make certain to
use the appropriate regulator for the application as recommended in the Instruction Manual.
b
a
h
i
c
d
e
k
j
f
g
(a)
(b)
(c)
(d)
(e)
(f)
(g)
18100933 - 34 L Regulator (1/2 L/min flow)
18102509 - 58/103 L Demand Flow Regulator
18103564 - 34 L Demand Flow Regulator
18102260 - 552 L Regulator (1/2 L/min flow)
18100883 - 58/103 L Regulator (1/2 L/min flow)
18102155 - 58/103 L Ammonia Regulator
18103580 - 58/103 L Bump Test Regulator
MX6 iNetDS shown with a
Demand Flow Regulator
(18105841) and cylinder
connected to an - iGas ®
Reader (18105684).
(h)
(i)
(j)
(k) 18105841 - 58/103/34L Demand Flow Regulator w/iGas Pressure Switch
18105833 - 552L Demand Flow Regulator, 590 CGA w/iGas Pressure Switch
18105858 - 650L Demand Flow Regulator, 330 CGA w/iGas Pressure Switch
18106740 - Demand Flow Regulator, 660 CGA w/iGas Pressure Switch
(l) 18105924 - 5-port Clamp-on Gas Manifold
demaNd flOW reGulatOrs
PART NO.
18105841
reGulatOrs
PART NO.
18100933
18102509
18103564
18103549
18103556
18104158
18106708
18102260
18100883
18102155
18103580
18103374
18104695
18104356
18105924
18109244
DESCRIPTION
(a) 34L Regulator (1/2L/min flow)
(b) 58/103L Demand Flow Regulator (and 34L Aluminum
Cylinders)
(c) 34L Demand Flow Regulator, CGA 600
552L Demand Flow Regulator, CGA 590
650L Demand Flow Regulator, CGA 330
Demand Flow Regulator, CGA 660
Demand Flow Regulator, CGA 705
(d) 552L Regulator (1/2 L/min flow), CGA 590
(e) 58/103L Regulator (and 34L Aluminum Cylinders)
(1/2 L/min flow)
(f) 58/103L Ammonia Regulator (1 L/min flow)
(g) 58/103L Bump Test Regulator w/Trigger
650L Regulator (1/2L/min flow), CGA 330
Regulator w/Bump Test Trigger, CGA 330
Regulator w/Bump Test Trigger, CGA 590
5-port Clamp-on Gas Manifold
18105866
18109243
18105833
18109241
18105858
18109242
18106740
18109246
18106757
18101766
DESCRIPTION
(h) 58/103/34L Demand Flow Regulator w/iGas 150 PSI
Pressure Switch
(h) 58/103/34L Demand Flow Regulator w/iGas 250 PSI
Pressure Switch
34L Demand Flow Regulator, 600 CGA w/iGas 150 PSI
Pressure Switch
34L Demand Flow Regulator, 600 CGA w/iGas 250 PSI
Pressure Switch
(i) 552L Demand Flow Regulator, 590 CGA w/iGas
200 PSI Pressure Switch
(i) 552L Demand Flow Regulator, 590 CGA w/iGas
500 PSI Pressure Switch
(j) 650L Demand Flow Regulator, 330 CGA w/iGas
200 PSI Pressure Switch
(j) 650L Demand Flow Regulator, 330 CGA w/iGas
500 PSI Pressure Switch
(k) Demand Flow Regulator, 660 CGA w/iGas
200 PSI Pressure Switch
(k) Demand Flow Regulator, 660 CGA w/iGas
500 PSI Pressure Switch
Demand Flow Regulator, 705 CGA w/iGas Pressure
Switch
58/103L Regulator (1 L/min flow)
