SPECIALTY WALL CABINETS
Built-In Microwave Cabinet (WMB)
WIDTH
INCHES
30
• 36” tall cabinet - upper door flips up
• Specify 36” tall to match 30” uppers (Fig A)
Specify 42” tall to match 36” uppers (Fig B)
Specify 48” tall to match 42” uppers (Fig C)
• 48” tall cabinet includes 1 shelf
• Not Available in Tripoli Door
See
Diagram
36”
42”
48”
Fig A
Cut Out Dimensions
WALL CABINETS
Width
30”
21”
Min
Max
Min
Max
21 7/8
26 7/8
15 3/4
22 3/4
• Side panels are always finished.
• Available in widths 30”, 36” & 42”,
with 24” depth bottom section and
12” depth top section
• Fits 22” deep Hood Liners
• Construction of Field-built Hood Vent box
conceals ducting (10” deep, faced with
12” x 36” drawer front)
• WHDA302424 can be matched with 36”
uppers, set at 68.8” off floor to bottom
• Not Available in Tripoli Door
24”
Pop-Out Hood Shroud Cabinet (WHDB)
15”
6”
24”
• Doors are functional for easy access
purposes
• Side panels are always finished
• Bottom section of 24” deep is 6” tall
before it pulls back to the 15” depth
(This section is not functional)
• Interiors will match exterior finished
ends in either laminate or real wood
veneer. Oak is not available in real
wood veneer.
• All components tops, bottoms,
backs and shelves are made with 5/8”
laminate furniture board.
• Not Available in Tripoli Door
Open Wall Corner Cabinet with Matching
Interior (WOAS)
12”
12”
• Wood frames are 1 1/2” wide
• Thermofoil frames are 2”
• Interiors will match exterior
finished ends in either laminate
or real wood veneer. Oak is not
available in real wood veneer.
• All components tops, bottoms,
backs and shelves are made with
5/8” laminate furniture board.
Letterbox Cabinet 12” Deep (WLB)
6”
12”
42”
HEIGHT
WMB304221
48”
HEIGHT
WMB304821
Fig B
Fig C
Height
Angled Hood Shroud Cabinet (WHDA)
12”
36”
HEIGHT
WMB303621
HEIGHT
INCHES
24
30”
WIDE
WHDA302424
36”
WIDE
WHDA362424
42”
WIDE
WHDA422424
48”
WIDE
WHDA482424
27
WHDA302724
WHDA362724
WHDA422724
WHDA482724
31
WHDA303124
WHDA363124
WHDA423124
WHDA483124
HEIGHT
42”
30”
36”
INCHES
WIDE
WIDE
WIDE
24
WHDB302424 WH
