HANGING VANITY CABINETS
Floating Sink Vanity Wall Cabinet (VW)
• Depending on bowl cutout,
front rail may need field
reinforcement
• Back is 5/8” thick
21 1/4”
WIDTH
INCHES
21
24
24
27
30
MODEL
NUMBER
VW21
VW24S
VW24
VW27
VW30
WIDTH
INCHES
33
36
39
42
MODEL
NUMBER
VW33
VW36
VW39
VW42
WIDTH
INCHES
12
15
18
21
24
MODEL
NUMBER
VW2D12
VW2D15
VW2D18
VW2D21
VW2D24
49
21”
Floating 2 Drawer Vanity Wall Cabinet (VW)
• Drawers have 10 1/2”
fronts with interior
clearance of 8 3/4”
• Back is 5/8” thick
21 1/4”
21”
Tips on Hanging Wall Units
Cut out for
sink bowl
• Units typically hung 9” to 13” off floor
• Plywood hang rail provides reinforced support
• Use a minimum of 4 anchors per cabinet (into studs), otherwise:
• Build half depth toe kick, or
• Use legs on front, or
• Use cleat on wall below cabinets
• Properly hung units will support up to 300 lbs. of weight at
front; however, you should not stand on these cabinets
VANITY CABINETS
9”-13”
off Floor
