28
BASE CABINETS
Base Cabinet w/ 3 Drawers (B3D)
• Top drawer front is 6” tall, interior clearance is 4 1/4”
• Bottom drawer fronts are 12” tall, interior clearance
is 10 1/4”
6”
12”
12”
WIDTH
INCHES
12
MODEL
NUMBER
B3D12
15
B3D15
18
B3D18
21
B3D21
24
B3D24
WIDTH
INCHES
12
MODEL
NUMBER
B4D12
15
B4D15
18
B4D18
21
B4D21
24
B4D24
WIDTH
INCHES
15
MODEL
NUMBER
B2PP15
18
B2PP18
21
B2PP21
24
B2PP24
24”
Base Cabinet w/ 4 Drawers (B4D)
• Top 3 drawer fronts are 6” tall, interior
clearance is 4 1/4”
• Bottom drawer fronts are 12” tall, interior
clearance is 10 1/4”
6”
6”
6”
12”
24”
Base Pot & Pan Cabinet w/ 2 Drawers (B2PP)
• Drawer fronts are 15” tall, interior clearance is 13 1/4”
• Standard Drawers: Drawer box is made of
laminated furniture board with full extension
side-mounted heavy duty ball bearing glides
• Dovetail Drawers: Drawer box is made of hardwood
with full extension side-mounted heavy duty ball
bearing glides (not available with soft close glide)
BASE CABINETS
15”
15”
24”
Base Pot & Pan Cabinet w/ 3 Drawers (B3PP)
6”
12”
12”
• Top drawer front is 6” tall, interior clearance is 4 1/4”
Bottom drawer fronts are 12” tall, interior clearance
is 10 1/4”
• Standard Drawers: Drawer box is made of
laminated furniture board with full extension
side-mounted heavy duty ball bearing glides
• Dovetail Drawers: Drawer box is made of hardwood
with full extension side-mounted heavy duty ball
bearing glides (not available with soft close glide)
WIDTH
INCHES
30
MODEL
NUMBER
B3PP30
33
B3PP33
36
B3PP36
24”
Base Cooktop Cabinet w/ 2 Drawers (B2CT)
6”
12”
12”
• Top drawer is non-functioning
• Bottom drawer fronts are 12” tall, interior clearance
is 10 1/4”
• Standard Drawers: Drawer box is made of
laminated furniture board with full extension
side-mounted heavy duty ball bearing glides
• Dovetail Drawers: Drawer box is made of hardwood
with full extension side-mounted heavy duty ball
bearing glides (not available with soft close glide)
WIDTH
INCHES
30
MODEL
NUMBER
B2CT30
33
B2CT33
36
B2CT36
24”
Corner Sink Base Kit (BSCK)
•
•
•
•
Requires adjacent cabinet, end panel or BDE
Requires 42” x 42” space
Cabinet includes 2 - 12” x 30” doors
Floor has parts sub-assembled with pocket screws for
quick installation
• Back corner clipped for out of square corners
• Uses Standard Hinges
24”
S=Single Door
WIDTH
INCHES
24
MODEL
NUMBER
BSCK42
