20
SPECIALTY WALL CABINETS
Built-In Microwave Cabinet (WMB)
See
Diagram
36”
42”
48”
WIDTH
INCHES
30
• 36” tall cabinet - upper door flips up
• Specify 36” tall to match 30” uppers (Fig A)
Specify 42” tall to match 36” uppers (Fig B)
Specify 48” tall to match 42” uppers (Fig C)
• 48” tall cabinet includes 1 shelf
• Not Available in Tripoli Door
36”
HEIGHT
WMB303621
Fig A
WALL CABINETS
48”
HEIGHT
WMB304821
Fig B
Fig C
Cut out Dimensions
30”
21”
42”
HEIGHT
WMB304221
Wall Microwave Shelf (WMS)
WIDTH
INCHES
24
27
• All 5/8” construction
• Use bridge cabinets above
Wall Microwave Shelf
15”
15”
HEIGHT
WMS241516
WMS271516
24”
27”
Angled Hood Shroud Cabinet (WHDA)
• Side panels are always finished.
• Available in widths 30”, 36” & 42”,
with 24” depth bottom section and
12” depth top section
• Fits 22” deep Hood Liners
• Construction of Field-built Hood
Vent box conceals ducting (10”
deep, faced with 12” x 36” drawer
front)
• WHDA302424 can be matched
with 36” uppers, set at 68.8” off
floor to bottom
• Not Available in Tripoli Door
12”
24”
Pop-Out Hood Shroud Cabinet (WHDB)
15”
6”
24”
• Doors are functional for easy
access purposes
• Side panels are always finished
• Bottom section of 24” deep is
6” tall before it pulls back to the
15” depth (This section is not
functional)
• Interiors will match exterior finished
ends in either laminate or real
wood veneer. Oak is not available
in real wood veneer.
• All components tops, bottoms,
backs and shelves are made with
5/8” laminate furniture board.
• Not Available in Tripoli Door
HEIGHT
INCHES
24
30”
WIDE
WHDA302424
36”
WIDE
WHDA362424
42”
WIDE
WHDA422424
48”
WIDE
WHDA482424
27
WHDA302724
WHDA362724
WHDA422724
WHDA482724
31
WHDA303124
WHDA363124
WHDA423124
WHDA483124
HEIGHT
42”
36”
30”
INCHES
WIDE
WIDE
WIDE
24
WHDB302424 WHDB362424 WHDB422424
48”
WIDE
27
WHDB302724 WHDB362724 WHDB422724 WHDB482724
30
WHDB303024 WHDB363024 WHDB423024 WHDB483024
33
WHDB303324 WHDB363324 WHDB423324 WHDB483324
36
WHDB303624 WHDB363624 WHDB423624 WHDB483624
Open Wall Corner Cabinet with Matching
Interior (WOAS)
12”
12”
• Wood frames are 1 1/2” wide
• Thermofoil frames are 2”
• Interiors will match exterior
finished ends in either laminate
or real wood veneer. Oak is not
available in real wood veneer.
• All components tops, bottoms,
backs and shelves are made with
5/8” laminate furniture board.
WIDTH
INCHES
12
30”
HEIGHT
WOAS1230
36”
HEIGHT
WOAS1236
42”
HEIGHT
WOAS1242
