18
WALL CORNER CABINETS
Wall Easy Reach Corner Cabinet (WEZ)
• Not available with soft close hinge
• Must specify Left or Right (L/R)
• Not Available in Tripoli Door
WIDTH
INCHES
21
30”
HEIGHT
WEZ2130L/R
36”
HEIGHT
WEZ2136L/R
42”
HEIGHT
WEZ2142L/R
24
WEZ2430L/R
WEZ2436L/R
WEZ2442L/R
12”
WALL CABINETS
Wall Diagonal Corner Cabinet (WC)
• Not available with soft
close hinge
• Must specify Left or Right (L/R)
• WC Available in Tripoli Door
• 1/4” spacer on back allows door
to align with adjacent cabinet
12” x 24”
15” x 27”
Wall Diagonal Corner
Glass Door Cabinet (WCGD)
WCGD models:
• Optional glass styles are
available-page 15
• Interiors will match exterior
finished ends in either laminate
or real wood veneer. Oak is not
available in real wood veneer.
• All components tops, bottoms,
backs and shelves are made with
5/8” laminate furniture board.
• WCGDNot Available in Tripoli
Door
Wood Door
WIDTH
INCHES
24
27
30”
HEIGHT
WC2430L/R
WC273015L/R
36”
HEIGHT
WC2436L/R
WC273615L/R
42”
HEIGHT
WC2442L/R
WC274215L/R
Glass Door
WIDTH
42”
30”
36”
INCHES
HEIGHT
HEIGHT
HEIGHT
24
WCGD2442L/R
WCGD2430L/R
WCG2436L/R
27
WCGD273015L/R WCG273615L/R WCGD274215L/R
WC24
WC27
12” x 24”
15” x 27”
Glass Door
Wall Blind Corner Cabinet w/ 1 Door (WB)
• Hinging specifications indicate the position of the
blind side (i.e., left hinge means blind is on the left)
• Not available with soft close hinge
• Must specify Left or Right (L/R)
• 24” Not available in Tripoli Door
• 27” – 36” Available in Tripoli Door
WIDTH
INCHES
24
30”
HEIGHT
WB2430L/R
36”
HEIGHT
WB2436L/R
42”
HEIGHT
WB2442L/R
27
WB2730L/R
WB2736L/R
WB2742L/R
30
WB3030L/R
WB3036L/R
WB3042L/R
33
WB3330L/R
WB3336L/R
WB3342L/R
36
WB3630L/R
WB3636L/R
WB3642L/R
12”
Wall Blind Corner Cabinet w/ 2 Doors (WB)
• Hinging specifications indicate the position of the
blind side (i.e., left hinge means blind is on the left)
• Not available with soft close hinge
• Available in Tripoli Door
12”
WIDTH
INCHES
39
42
30”
HEIGHT
WB3930
WB4230
36”
HEIGHT
WB3936
WB4236
42”
HEIGHT
WB3942
WB4242
45
WB4530
WB4536
WB4542
A
B
INCHES
C
MIN PULL
INCHES
D
MAX PULL
INCHES
INCHES
WB24xx
21
9
22
26
WB27xx
WB30xx
24
12
25
29
27
15
28
32
WB33xx
30
18
31
35
WB36xx
33
21
34
38
WB39xx
36
2 x 12
37
41
WB42xx
39
2 x 13
40
44
WB45xx
42
2 x 13
43
47
CABINET BOX WIDTH DOOR WIDTH
D
C
A
Shown as left
B
Blind Wall Cabinets can be set to the
code’s width. Example a WB3630 can
be set at 36" which leaves a 3” space.
A Min. of 1" filler must be
used to clear adjacent cabinet.
