Electric Fence 101
Ground System Moisture is the conductor of electricity in the ground field and is critical for completing the circuit . This is the key to a good electric fence and is often the most common source of failure . Consider that the grounding system is similar to a television antenna ; the larger the antenna , the greater the reception will be . Ground rods serve to collect the voltage from the fence and deliver it back to the charger through the earth . The amount of shock felt by the horse is directly proportional to the amount of power returned back to the fence from moisture at the grounding field . Therefore , it is critical that the field is large enough to collect all available power .
We recommend at least 3 ground rods , 5 ’ long and spaced 10 ’ apart in an area of constant ground moisture . Ground beds should be a minimum of 30 ’ and preferably 50 ’ from one another if multiple ground beds are used . Never install ground rods within 50 ’ of utility ground , buried water lines , or telephone poles . In some situations , the grounding field is less than optimal . This would include very welldrained soil , sandy soil , deeply frozen soil , or very rocky conditions . In all of these cases , there is a lack of moisture in the ground field . In these suboptimal conditions , multiple ground fields are often required as well as a ground wire for electricity to the fence . If your soil conditions fall into these categories , please speak with one of our representatives to determine the best setup for your situation . It is essential to be sure all connections are tightly secured . Be sure proper hardware and underground burial wire is used with electric fences . a
