NEW LOCAL HVLS FAN
Supplied by EverBreeze , these High Volume Low Speed ( HVLS ) fans are typically ceiling mounted . They turn at low speeds , producing continuous air columns that move gently to provide a natural evaporative cooling effect .
HVLS fans do not add or remove thermal energy to the air . Rather , they move large masses of air with very little energy consumption and enhance the processes of evaporation and destratification .
Product applications include :
• Factories , warehouses , and distribution centres
• Agricultural storage and food processing plants
• Breweries and bottling plants
• Public retail and leisure spaces
• Libraries and other academic environments
• Transport hubs
Unit range includes :
• Fan : Diameters range from 3.9m to 7.4m with 1 000 to 4 200 m ² coverage area respectively .
• Motor : IE3 premium efficiency 4-pole geared motor , IP55 rated and self-ventilated .
• Aerofoils : Anodised aluminium made from aircraft grade alloy .
• Drive : High-performance variable speed drive housed in ventilated steel enclosure and fitted with isolator and circuit breaker .
Controller :
• Variable speed control
• Forward / Reverse function
• Error code display for troubleshooting
Safety features :
• Hub retainer safety system
• Guy wires
• Safety cables
• Accelerometer
• Fire detection system if applicable
For more information , call + 27 ( 0 ) 79 877 5592 / ( 0 ) 82 499 3255 .
NEW R32 SMALL INVERTER CHILLER
The Daikin Bluevolution range has been completed with the introduction of the R-32 Small Inverter chiller – an air-cooled chiller and heat pump series .
This series boasts a fantastic capacity range and a compact form , leading to a wide operating envelope . We are also proud to have developed the highest efficiency ratings on the market . The launch of this product completes Daikin ’ s R-32 product family for the commercial air conditioning segment .
The product features include :
• Latest modern and advanced components
• Suitable for small to medium buildings
• 3 different models with a footprint between 0.9m2 – 2.82m2
• R32 refrigerant offers higher efficiency and lower CO2 emissions
• Cooling only and heat pump configurations º Cooling capacity range : 15.9kW – 88.3kW º Heating capacity range : 15.9kW – 85.8kW
• Operating range : -20 ° C to + 52 ° C ( with high temp kit ) – std -20 C to + 45 ° C
• Provide chilled water between -15 ° C and + 25 ° C
• Full inverter technology on scroll compressor and fan motor provides increased efficiency in full and part load with EER up to 3.16 and COP up to 3.45
• Optimised copper aluminium coils and brazed plate heat exchanger
• Antifreeze protection
• Improved connectivity to BMS and IoT
• Master and slave option allows connection of up to 4 units
• Remote monitoring and real time evaluation and actions
• New control methodology allows maintenance planning notifications and lists spares required
For more information , call + 27 ( 0 ) 11 997 4400 / + 27 ( 0 ) 21 528 3500 .
