passing through the systems constantly would corrode any copper items . Steel tubing is also an option in the case of ammonia systems and historically it was the norm but has made way for SS as tube material for the greater part .
The designed operating pressures of the coil influence the material thickness . Larger diameter tubes inherently have a lower operating pressure limit from the same material . Hence smaller diameter tubes are used when a higher operating limit is need . Should copper tubing not offer a safe operating pressure SS is commonly used . SS tubing is commonly tungsten inert gas ( TIG ) welded or fused .
• Fin materials The greater majority of fin and tube coils are made with aluminium alloy fins . Aluminium is light and easy to process in big volumes and offers the best heat transfer value for money . A variety of thicknesses and alloy variations are generally on offer depending on the applications . The greatest majority of all fin and tube type heat exchangers would be making use of regular aluminium fin material .
With a constant mass of air drawn across an air-cooled condenser the fin material is exposed to potentially corrosive elements constantly . Corrosion to the fin material lowers the unit ’ s potential heat transfer capability of the coil . In acid environments the outer surface other coil could be coated with a suitable epoxy coating to reduce the corrosion rate .
“ How good are these coatings ” is a question often asked . Testing done in accordance with ASTM B117 norms ( 5 % NaCl , 35 ° C ) showed epoxy coated fin materials to last 4-7 times longer than bare aluminium fins . Epoxy coating is therefore a good option to consider in acidic or salty environments . An epoxy coating would be applied to the coils outer surface area after the coil is completed .
In some cases where a large amount of condensate would be present on the aluminium fin area for prolonged periods corrosion is also accelerated . A hydrophilic coating on the fin ’ s surface materials offer a lower surface tension and allows the water droplets to flow off the aluminium easier . In this case the hydrophilic coating is applied to the aluminium fin material during production of the fin material , so it is not added at a later stage during manufacturing as it the case with epoxy coatings .
This solution also offers good resistance to corrosion in salty or acid environments . Comparative tests according to ASTM B117 norms ( 5 % NaCl , 35 ° C ) have shown hydrophilic coated fins to last up to 3 times longer than unprotected aluminium fins ( Friterm 2004 ).
The closer the fins are together the greater the surface area available for the heat transfer to take place . The fins are cut and shaped from the raw material into the required sizes . A collar is shaped to be the contact area between the fins and tubes and serves as suitable fin spacing .
Another alternative material is copper fins . Copper is an alternative to aluminium in more acid or salty environments . Copper is of course significantly heavier and offer a slightly better potential heat rejection that will in return effect the solution ’ s specific U-value . The copper fin materials could also be epoxy coated to improve resistance to corrosion .
PLANNED MAINTENANCE A factor that affects the fin material life span like with most things is the specific preventative maintenance required . The huge volumes of ambient air drawn across an air-cooled condenser application contains dust particles and other airborne particles . These enter the fin face area and restricts the air flow . Less air flow means less heat rejection is now taking place every hour in operation .
The inlet of the coil face needs to be cleaned on a regular basis to remove restrictive matter . Any mould that might have accumulated also needs to be cleaned since it might pose health and safety risks . Cleaning condenser coils thoroughly is crucial but often quite challenging task . A suitable coil cleaning solution needs to be applied to removed greasiness and dust . A thorough rinse is needed to remove the dust and cleaning solution .
A slightly acidic solution allowed to dry on the finned area is likely to result in corrosion . Ideally the system would need to be switched off in order for the condenser to cool down to close to ambient conditions ( the discharge gas / vapour might be close to 100 ° C in operation ) as part of any Standard Operating Procedure ( SOP ). It is obviously a challenge in many applications to switch a system off for an hour or two with goods in the freezer room gaining temperature .
Many cleaning solutions applied and not thoroughly rinsed prior to the condenser coil placed in operation again might well adversely affect the fin material and reduce the unit ’ s ability to reject heat energy . Follow the required procedures as specified by the developer to the cleaning agent is a crucial part of the servicing SOP . RACA
