The building render of the entrances to the office and apartments as well as the entertainment venues .
manufacturer ’ s restrictions on the equipment . On the 7 th floor and every subsequent second floor , there are plant rooms for the outdoor units .
However , these plant rooms have size limitations . Therefore , a request for a Computational Fluid Dynamics ( CFD ) analysis was sent to the Samsung Head Office in Korea in order to determine if the outdoor units would be able to operate , within these restrictions , inside these plant rooms .
The area of the plant room , as well as its layout and the positions of the condensing units were required in order to perform the CFD analysis . As shown in the layout modelling image on page 29 , case 1 was rejected due to the recirculation of hot air caused by the position of the condensers . It was then advised to reposition the condensing units , as per Case 2 , as this simulation was successful . RACA
LIST OF PROFESSIONALS : Project name : Umhlanga Arch Developer
Devmco
Architect / Designer COA ( Pty ) Ltd
Project manager
M3 Africa Electrical Mechanical
Consulting engineer
Wet services Civil Main building HVAC & R
Contractors
Wet services Electrical Samsung Samsung Voltas Blue Box
HVAC and associated product suppliers
Evapco Rickard Sunwind AMS
CKR Consulting Spoormaker and Partners CKR Consulting
WBHO Luft Technik Starling Plumbers Electrical Project DX Split units VRF Equipment Air Handling Units Chiller Cooling Towers Air Terminal Fan Coil Unit Fans
