MASTERING EVAPORATOR SELECTION
By Eamonn Ryan
From nominal duty to practical application.
At the October SAIRAC Cape Town Centre TechTalk, Marius la Grange – general manager of Thermocoil Cape Town and a past SAIRAC president – took delegates through the fine art of choosing the right evaporator. Far from a matter of simply picking a unit from a catalogue, he stressed, it’ s a disciplined balance of science, standards and experience. Correct selection determines not only how well a system cools, but how efficiently, reliably and comfortably it performs over its lifetime.
The starting point, La Grange explained, is understanding nominal duty – the amount of heat the coil must remove to maintain the desired room temperature. That begins with four fundamentals: the room set-point, the suction temperature, the refrigerant and airflow characteristics.
Consider a customer wanting to keep a space at 16 ° C. With a ΔT( difference between room and suction) of 10K, the suction temperature must be 6 ° C. Using the manufacturer’ s conversion tables, this yields a correction factor of 1.6. Thus, an evaporator rated at 2.4kW under standard conditions would easily handle the duty required for those conditions.
Every manufacturer’ s catalogue – be it Thermocoil, Heat Exchange Centre or Colcoil – follows the same Eurovent-certified method, which allows direct comparison between brands under identical laboratory conditions. Eurovent defines standard test points: SC2 for medium-temperature rooms( air in at 0 ° C, suction-8 ° C) and SC3 for low-temperature storage( air-18 ° C, suction-25 ° C). These nominal values are the baseline, to be corrected for the refrigerant used and the coil’ s material.
Two key correction factors apply: F1, which adjusts for the refrigerant’ s latent heat of vapourisation, and F2, for fin or tube materials. Multiply the nominal duty by both to find true coil capacity.“ Each refrigerant absorbs heat differently. A kilogram of R290, for example, removes almost twice the heat of R22 when it boils,” said La Grange.
COIL DESIGN AND APPLICATION Evaporator coils are fin-and-tube heat exchangers on the lowpressure side of a direct-expansion system. As liquid refrigerant evaporates inside the coil, it absorbs heat from the room air and exits as superheated vapour ready for compression and heat rejection at the condenser.
