© GVK Siya Zama result from human activities which modify or are likely to modify the ozone layer ”.
The intent of this Protocol is to specifically assist in the reduction of the depletion of the ozone layer through the use of ozone-friendly gases .
The Kyoto Protocol was then established to support the Montreal Protocol and South Africa is not ony a signatory to these Protocols , but also a signatory to all of the ratifications thereto , binding the country by international convention to maintain the prescriptions and requirements . Not knowing or abiding with the intent or
Atop the gymnasium roof a 112kW solar PV array is installed . Here too the plant deck for the gymnasium indicating the packaged VRF system and ducting to-and from the building . application of the content of these international treaties is considered negligent .
The gymnasium posed the most significant challenge in the HVAC design for this project , purely due to its sheer size – a monstrous void that houses various possible indoor activities and along with that – variable occupancy . Attached to the gymnasium itself is something similar to a minuature version of a gym or health club circuit , and the HVAC system installed there needed to run independently on its own AC system when the main gymnasium was not being used .
Technical difficulties that needed to be addressed in this project , and specifically under the changes in regulations imposed by the global Coronavirus pandemic that has caused severe issues with health and indoor air quality , in June 2020 the South African government issued a gazette ( 43400 ) that specifies all return air must be filtered through high efficiency particulate filters ( HEPA ) which provide a 95 % effective filtration at 0.3 microns . A custom sterilisation system ( described above ) was therefore designed and supplied to meet these requirements in the gymnasium .
UNIQUE ELEMENTS AND EFFICIENCY The custom system that has been installed in the gymnasium makes it one of the most advanced in the country – there is only one other system like this that is operating at a hospital in Klerksdorp in the North West Province , with the same
Patterson Park Recreation Centre has all the facilities a community could need from a library to an auditorium , craft centre , near-olympic sized swimming pool and gymnasium .
© GVK Siya Zama
34
RACA Journal I March 2021 www . hvacronline . co . za
