RACA Journal January 2024 | Page 45

Products

DEKA CONTROLS BALL SHUT-OFF VALVES DBV

Compact housing for operating pressures up to 45 bar :

• Optimum flow rate with low pressure drop

• Connections in metric and imperial design

• CE marking according to the Pressure Equipment Directive 2014 / 68 / EU

• With threaded hole for fastening

• Hermetic design

• Valves can be sealed

• Pressure-relieved cap for safety when opening

• Seat seal , filled PTFE for low frictional forces

• Spindle sealing by means of O-rings and PTFE Flat gasket ( additionally reduces the required torque )

• 100 % testing with helium for external tightness

• Optional : type DVB-xxxS with Schrader valve ( 7 / 16 " -20 UNF )

• Also for natural refrigerants and in high-pressure version DBVH up to 120bar

• Also with stainless steel connection on request

PRODUCT HIGHLIGHTS :

• Precise troublefree operation due to pressure detection by load cell with powerful output signal

• Absolute pressure measurement by comparison with sealed reference pressure standard

• Output signal 4 to 20 mA

• Calibrated pressure ranges for specific temperatures and for refrigeration and air conditioning applications

• Immune to vibration and pulsation

• CE mark in compliance with EMC Directive

• Protection class IP 67

• Quick-action connection with M12 plug connector and pre-assembled connecting cable with different lengths

For more information call + 49 7141 702063

THE DAIKIN R-32 VRV CHILLER – AVAILABLE IN SPLIT VERSION WITH R-32 REFRIGERANT

New split-version models have been added to the Daikin R-32 VRV Chiller series in late summer 2022 . This addition to Daikin ' s extensive portfolio of VRV chillers uses climatefriendlier R-32 refrigerant .

EFFICIENT HEATING AND COOLING The inverter-controlled heat pump is available in 21-64kW capacity classes and can be used for heating and cooling buildings of different sizes . The Daikin R-32 VRV Chiller easily adapts to different cooling and heating requirements with supply temperatures of + 60 ° C for heating or

-15 ° C in cooling mode . With a SEER ( seasonal energy efficiency ratio ) as high as 5.7 and a SCOP ( seasonal co-efficient of performance ) up to 4.2 , this heat pump delivers remarkable efficiency with low running costs . Thanks to its compact design and integrated safety system , the heat pump can be installed in tight spaces .

FOCUS ON SUSTAINABILITY Daikin is planning to convert its entire portfolio of chillers that use R-410A refrigerant to the more climate-friendly R-32

refrigerant . While R-410A refrigerant has a GWP ( globalwarming potential ) of 2 088 , the GWP for R-32 is only 675 – which significantly reduces CO 2 emissions . Following the introduction of a compact version of the R-32 chiller in October 2021 , the entire production of the corresponding R-410A series was relocated from Ostend in Belgium to Italy .

The same process is being carried out for the split version of the chiller . By switching its entire product range to R-32 refrigerant , Daikin is setting a benchmark for sustainability and the futurefocused development of the industry .

For more information call + 27 ( 0 ) 11 997 4400
