Products
SAFER SPRINKLERS
Victaulic’s FireLock IGS Style V9 Sprinkler Coupling and Grooved
Sprinklers have not only eased the manner and speed in which fire
protection systems are installed but offer increased job site safety
and system confidence.
A single bolt makes up the joining of the innovative coupling
design, which in turn is fitted onto sprinklers with a connection
size of 12.7mm, 19.05mm or 25.4mm, and transitions to 25.4mm
allowing for the standardisation of 25.4mm IGS outlets making the
project easier to plan, design and weld. The simplification of the
coupling leads to simplified installation, which increases not only
on-site job safety, bit allows for ease of maintenance in the future. For more information, contact +27 (0) 11 463 2198.
EASY FLOWS
Instrotech is offering Kobold’s VKP plastic
flowmeters that operate on a special suspended
float principle with cylindrical measuring tube
and spring-loaded float with orifice. The float in
model VKP-3 has slots mounded onto the outside,
which protect the instrument from soiling by
capturing dirt particles. The danger of the float
jamming is thus considerably reduced and soiled
liquids with a particle size up to 400m can be
measured without difficulty. In model VKP-2,
the sharp-edged orifice in the float renders the
instrument less sensitive to changes in viscosity.
The model VKP finds application in lubricant
circuits, domestic electrical, installations, machine
tools, solar energy systems, cooling circuits, welding
machines, and pumps.
For more information, contact +27 (0) 10 595 1831.
FANNING LOWER THAN USUAL
Did you know that our Zeihl-Abegg ZAplus nozzle can be used at
low temperatures applications? Our high-performance composite
material made of PP GF40 allows the operating up to -60°C ambient
temperature. The material property doesn’t change appreciable
between -40°C and -60°C.
Generally, the approval applies for the mentioned component.
The complete fan (and article) must fulfil the application rules
according the technical document, L-AH-0044. With ZAplus we are
able to offer a complete fan system without the expensive motor
suspension or casing made of stainless steel. For more information, contact +27 (0) 11 974 4211.
Do you have any new and exciting products to share with the industry?
Email your short write-up and product image to [email protected]
www.hvacronline.co.za RACA Journal I August 2020 57
