TS-x53 Pro / SS-x53 Pro Series
Hardware Introduction
Eco-friendly design
The UX series automatically powers on/off with your Turbo NAS, allowing for total convenience and energy saving. The
hard drives in the UX series can be configured to enter sleep mode after the system becomes idle after a preset period of
time, extending their lifetime and saving you money on energy bills.
Powerful QTS Storage Manager
The QTS Storage Manager neatly presents tools and options for managing system storage with a modern & intuitive
graphical user interface, which greatly simplifies the process of NAS capacity expansion and UX-800P/UX-500P
management. No matter if you are an IT administrator or general user, you can easily monitor the status of UX-800P/
UX-500P and the disks within it.
Step 1: Connect the UX-800P/UX-500P to the NAS
using USB 3.0.
Step 2: Log in to the QTS Storage Manager.
Step 3: Create new volumes and shared folders on
the UX-800P/UX-500P.
QNAP USB 3.0 Expansion Enclosure
UX Expansion Enclosure
Supported HDD/SSD
Types
UX-500P
UX-800P
5 x 3.5" or 2.5" SATA 6Gb/s,3Gb/s
8 x 3.5" or 2.5" SATA 6Gb/s,3Gb/s
5 hot-swappable HDDs and lockable bays
8 hot-swappable HDDs and lockable bays
Yes (using QNAP Storage Manager)
Yes (using QNAP Storage Manager)
1 x USB 3.0 (Back)
1 x USB 3.0 (Back)
Power, network and status
Power, network and status
Monochrome-LCD display (with backlight)
Monochrome-LCD display (with backlight)
Kensington lock
Kensington lock
Silent fan x 1 (12 cm, 12V DC)
Silent fan x 1 (12 cm, 12V DC)
Input: 100-240V AC, 50/60Hz, Output: 250W
Input: 100-240V AC, 50/60Hz, Output: 250W
Form Factor
Tower
Tower
Temperature
5°C ~ 35°C (40°F ~ 95°F)
5°C ~ 35°C (40°F ~ 95°F)
5~95% RH; Web bulb: 27˚C
5~95% RH; Web bulb: 27˚C
Max. Number of HDDs
and HDD Bays
RAID Management
USB Ports
LED Indicators
LCD Panel
Anti-theft Design
Fan
Power Supply
Specification
Humidity
49
TS-x53 Pro/SS-x53 Pro，Powered by QNAP's exclusive QvPC Technology
