PROMAG THIRD QUARTER 2014 - VOLUME 22 NUMBER 3 | Page 18
featured products
DMPS3-150-C: 3-Series® DigitalMedia™ Presentation System 150
Provides a 4K multi-format presentation switcher with fully automatic operation and DigitalMedia™ connectivity. Works seamlessly out of the box
with up to four Crestron Connect It™ tabletop interfaces.
Ideal for single-display presentation in a small conference room, huddle room, or collaboration room, the DMPS3-150C provides fully automatic
operation and works seamlessly out of the box with up to four Crestron Connect It™ tabletop interfaces. The 4K DMPS3-150-C is uniquely designed
to present higher native resolution sources such as 2560x1600 output from Apple® laptops, which require more bandwidth than ordinary 1080p
switchers can handle. Even better, the DMPS3-150-C is pre-programmed for super-fast installation. Get your system up and running directly from
the touch screen by answering a few simple questions. Simply select your sources and displays, and label icons.
KEY FEATURES
•
•
•
•
•
•
•
•
10x1 4K multi-format presentation switcher
Support for today’s high-resolution laptops — anything up to •
•
4096x2160
•
Provides the core of a complete Crestron Connect It™ solution
•
Four HDMI® and four VGA/analog video inputs
•
Four stereo analog audio inputs
•
Two DM® or HDBaseT® inputs
•
HDMI and DM or HDBaseT outputs
Built-in 4K scaler
Balanced stereo audio output
Fully automatic switching
Single microphone input for voice-lift
Display control via IR, RS-232, CEC, or Ethernet
Fully-programmable 3-Series® control system
Built-in universal power supply — no wall-warts
1U rackmount or under table mount
SAROS_PD6T: Saros® 6.5” 2-Way Pendant Speaker
Watts (program), with a wide frequency response from 50 Hz to 20 kHz
(±3 dB).
KEY FEATURES
•
High-performance
suspended
speaker
for
open-ceiling
applications
•
Weather-resistant for use under eves and in semi-enclosed spaces
•
6.5" polypropylene woofer with damped cloth surround for tight,
controlled bass and clear midrange
•
Optimized dual front ports for enhanced low-frequency response
•
Wide-dispersion, horn-loaded titanium dome tweeter for crisp,
clear high-end and enhanced pattern control
Complete your installation with Crestron speakers. Saros® pendant
speakers are designed to deliver excellent speech intelligibility and
•
Built-in 60 Watt 70/100V multi-tap transformer
full, rich music reproduction for use in open-ceiling spaces such as
•
125 Watts program power handling at 8 Ohms
restaurants, night clubs, retail spaces, houses of worship, and convention
•
50Hz-20kHz frequency response
facilities. Solid construction and a number of feature enhancements
•
100° nominal coverage pattern
ensure a quick and easy installation and years of reliable performance.
•
Rigid glass fiber reinforced ABS construction
•
Magnetically attached steel frameless grille
The Saros PD6T model is a 2-way pendant speaker featuring a 6-1/2
•
Available in black or white
inch woofer and wide-dispersion, horn-loaded 1 inch dome tweeter. A
•
