1.0 TENSION

1.2 Concrete Breakout Failure Mode
Variables c a , min
Variables ACI 318-19 Chapter 17 Provision Comments for PROFIS Engineering
c a , min
17.6.2.1.1 A Nc is the projected concrete failure area of a single anchor or of an anchor group that is approximated as the base of the rectilinear geometrical shape that results from projecting the failure surface outward 1.5h ef from the centerlines of the anchor , or in the case of an anchor group , from a line through a row of adjacent anchors . A Nc shall not exceed nA Nc0
, where n is the number of anchors in the group that resist tension . 17.6 . 2.1.4 A Nc0 is the projected concrete failure area of a single anchor with an edge distance of at least 1.5h ef and shall be calculated by Eq . ( 17.6.2.1.4 ).
A Nc0
= 9h ef
2
( 17.6.2.1.4 )
17.6 . 2.4.1 Modification factor for edge effects for single anchors or anchor groups loaded in tension , ψ ed , N
, shall be determined by ( a ) or ( b ).
( a ) If c a , min ≥ 1.5h ef
, then ψ ed , N = 1.0 ( 17.6.2.4.1a )
( b ) If c a , min < 1.5h ef
, then ψ ed , N = 0.7 + 0.3 c a , min ( 17 . 6 . 2 . 4 . 1b )
1.5h ef c a , min is defined as the “ minimum distance from the center of an anchor shaft to the edge of concrete .” When one or more fixed edges are modeled in PROFIS Engineering , the report will show the smallest fixed edge as “ c a , min
” in the
Variables section .
Excerpted ACI 318-19 anchoring-to-concrete provisions and equations that include c a , min for calculating concrete breakout strength in tension are shown to the left . Reference the parameters A Nc and A Nc0 in the Equations section of the PROFIS Engineering report for more information on the following parameters :
c a1
: distance from the center of an anchor shaft to the edge of concrete in one direction ( e . g . the x + direction ). For tension calculations , c a1 is the smallest fixed edge distance . c a2
: distance from the center of an anchor shaft to the edge of concrete in a direction perpendicular to ca1 ( e . g . the y + direction ).
Reference the parameters ψ ed , N and ψ cp , N in the Equations and Calculations sections of the PROFIS Engineering report for more information on how ca , min is used to calculate these parameters .
17.6.2.6.1 Modification factor for post-installed anchors designed for uncracked concrete in accordance with 17.6.2.5 without supplementary reinforcement to control splitting , ψ cp , N
, shall be determined by ( a ) or ( b ) using the critical distance c ac as defined in 17.9.5 .
( a ) If c a , min ≥ c ac
, then ψ cp , N = 1.0 ( 17.6.2.6.1a )
( b ) If c a , min < c ac
, then ψ cp , N =
c a , min
1.5h ef ( 17 . 6 . 2 . 6 . 1b )
c ac
c ac
