ψ ed , Na
= 0.7 + 0.3
|
c a , min ≤ 1 . 0
c Na
|
17.6.5.4.1 Modification factor for edge effects for single adhesive anchors or adhesive anchor groups in tension , ψ ed , Na
, shall be determined by ( a ) or ( b ) using the critical distance c Na as defined in Eq . ( 17.6.5.1.2b )
( a ) If c a , min > c Na
, then ψ ed , Na = 1.0 ( 17.6.5.4.1a )
( b ) If c a , min < c Na
, c a , min ( 17 . 6 . 5 . 4 . 1b )
then ψ ed , Na = 0.7 + 0.3
c Na
|
When calculating the nominal concrete pryout strength in shear ( V cp or V cpg
), the parameter ψ ed , Na is a modification factor that accounts for fixed edge distances less than c Na , where c Na corresponds to a calculated value representing a projected distance from the center of an adhesive anchor . The illustration below shows how the assumed area of influence with respect to pryout ( A Na
) would be defined for an anchoring application being modeled with two fixed edges ( c a1 and c a2
) that are both less than c Na , and with c a1 being less than c a2 . The smallest edge distance ( c a1 ) corresponds to the parameter c a , min
, and would be used to calculate the modification factor ψ ed , Na .
|
17.6.5.1.2 ………………………………….. |
|||
where |
|||
|
c Na
= 10d a т uncr ( 17 . 6 . 5 . 1 . 2b ) 1100
|
|||
ψed , Na = 0.7 + 0.3 ( ca1 / cNa ) |
|||
|
It is important to understand that “ ψ ed , Na
” calculated for bond failure in tension is not necessarily the same as “ ψ ed , Na
” calculated for concrete pryout failure in shear since the number of anchors in tension may not be the same as the number of anchors in shear .
|
|||
|
Reference the Variables section of the PROFIS Engineering report for more information on the following parameter :
c a , min
: parameter for the smallest fixed edge being modeled .
|
|||
|
Reference the Calculations section of the PROFIS Engineering report for more information on the following parameters :
c Na
: edge distance parameter for adhesive anchors
ψ ed , Na
: modification factor for edge distance
|
