2.0 SHEAR
2.1 Concrete Breakout Failure Mode
Variables d a
( continued )
Variables ACI 318-19 Chapter 17 Provision Comments for PROFIS Engineering
d a
Excerpt from ESR-3187 ( HIT-HY 200 adhesive anchor system ) showing the diameter range for threaded rods and rebar . These nominal diameters are used to calculate V b
.
Table 12 — Concrete breakout design informatian for fractional threaded rod and reinforcing bars in holes drille with a hammer drill and carbide bit ( or hilti hollow carbide drill bit )
DESIGN INFORMATION Symbol Units
3 / 8 or # 3
1 / 2 or # 4
Nominal Rod Diameter ( in ).
Minimum Embedment h ef , min in . 2-3 / 8 2-3 / 4 3-1 / 8 3-1 / 2 3-1 / 2 4 4-1 / 2 5
Maximum Embedment h ef , max in . 7-1 / 2 10 12-1 / 2 15 17-1 / 2 20 22-1 / 2 25
Minimum Concrete Thickness
5 / 8 or # 5
3 / 4 or # 6
7 / 8 or # 7 h min in . h ef + 1-1 / 4 h ef
+ 2d 0
1 or # 8
# 9
1 / 4 or # 10
Excerpt from ESR-1545 ( HSL-3 mechanical anchor ) showing the anchor diameter range . The diameter in bold text ( e . g . M10 , M12 , etc .) is the nominal diameter of the threaded element in the anchor . The outside anchor diameter (“ Anchor O . D .”) corresponds to the diameter of the external sleeve . The outside sleeve diameter is used to calculate V b
.
Table 3 — Design information
Design parameter
Symbol Units
Nominal anchor diameter M8 M10 M12 M16 M20 M24
|
( d ) 9
|
mm |
12 |
15 |
18 |
24 |
26 |
32 |
Anchor O . D . |
d a 0
|
in . |
0.47 |
0.59 |
0.71 |
0.94 |
1.10 |
1.26 |
external sleeve " Anchor O . D ."
