ψ cp , Na
= MAX
|
c a , min , c Na ≤1 . 0
c ac
c ac
|
17.6.5.5.1 Modification factor for adhesive anchors designed for uncracked concrete in accordance with 17.6.5.1 without supplementary reinforcement to control splitting , ψ cp , Na
, shall be determined by ( a ) or ( b ) where c ac is defined in 17.9.5 .
( a ) If c a , min ≥ c ac
, then ψ cp , Na = 1.0 ( 17.6.5.5.1a )
( b ) If c a , min < c ac
, then ψ cp , Na =
c a , min
≥
c Na ( 17 . 6 . 5 . 5 . 1b )
|
ψ cp , Na is a modification factor that considers splitting failure when calculating the nominal bond strength in tension ( N a or N ag
) for an adhesive anchor system . Since ACI 318 anchoring-to-concrete provisions do not specifically consider concrete splitting as a failure mode , splitting is addressed through the ψ cp , Na modification factor . The parameter ψ cp , Na is only considered when designing adhesive anchors installed in uncracked concrete . Splitting failure will typically not occur for castin-place anchors ; therefore , a splitting modification factor is not calculated in PROFIS Engineering when modeling cast-in-place anchors .
|
|
17.6.5.5.2 For all other cases , ψ cp , Na shall be taken as 1.0 .
c ac
c ac
17.9.5 Critical edge distance cac shall be in accordance with Table 17.9.5 unless determined from tension tests in accordance with ACI 355.2 or ACI 355.4 .
Table 17.9.5 – Critical edge distance
Post-installed anchor type
Torque-controlled
Displacement-controlled
Screw
Undercut
Adhesive
Critical edge distance c ac
4 h ef
4 h ef
4 h ef
2.5 h ef
2 h ef
|
Splitting failure is influenced by the distance of an anchor from a fixed edge “ in a region of a concrete member where analysis indicates no cracking at service load levels ”. The parameter cac that is used to calculate ψ cp , Na is defined in ACI 318 as the “ critical edge distance required to develop the basic strength as controlled by concrete breakout or bond of a post-installed anchor in tension in uncracked concrete without supplementary reinforcement to control splitting .” ψ cp , Na does not need to be calculated if the smallest fixed edge distance ( c a , min ) is greater than or equal to c ac
, or if cracked concrete conditions are assumed . Testing per the ICC-ES acceptance criteria AC308 and the ACI test standard ACI 355.4 is used to derive c ac values for adhesive anchor systems . c ac values derived from this testing are provided in an ICC-ES evaluation report ( ESR ). ACI 318-19 Table 19.9.5 provides c ac
-value for post-installed anchors ; however , these values are only intended to be used as “ guide values ” in the absence of c ac
-value derived from product-specific testing . PROFIS Engineering uses the c ac
-value that is given in the ICC-ES evaluation report for an adhesive anchor system to calculate ψ cp , Na
.
The value for ψ cp , Na that PROFIS Engineering calculates will be limited to MAXIMUM { c a , min
/ c ac : c Na
/ c ac } where c a , min is the smallest fixed edge distance being modeled in the application and c Na corresponds to an assumed projected distance from the center of the adhesive anchor element calculated per Equation ( 17.6.5.1.2b ).
|
||
|
Reference the Variables section of the PROFIS Engineering report for more information on the following parameters :
c a , min
: the smallest fixed edge distance being modeled .
c ac
: value derived from testing per AC308 / ACI 355.4 for the adhesive anchor system being modeled .
|
|||
|
Reference the Calculations section of the PROFIS Engineering report for more information on the parameter c Na
.
|
