Direct Fastening Technical Guide , Edition 24
Fastener notes :
● = Single M = Collated fasteners ( magazine required ) P8 = 8 mm fastener guide required
DX 351
DX 2
DX 5 / DX 460
GX 3 / BX 3
2021 Direct Fastening Technical Guide
Fastener
Application
Section numbers
Page numbers
X-EMTSC MX Stand-Off Conduit Clip
For stand-off conduit applications
● ● ● 3.2.17 102 – 111
X-ECH / F Cable Holder
For suspending cable from concrete or steel
Note : Requires ECH adapter . ● ● 3.2.17 102 – 111
X-EKB MX Cable Clamp
For clamping cable to concrete or steel
● ● ● 3.2.17 102 – 111
X-ECT MX Cable Tie Fastener
For cable tie applications . To be used with magazine tools and non-Hilti supplied cable tie . ● ● ● 3.2.17 102 – 111
X-IE Insulation Fastener Family
For attaching mineral wool , EPS , XPS , PIR , PUR , wood-wool and fiber-cement faced boards to concrete or steel .
Note : Requires X-IE Conversion Kit , DX-5 IE or GX-IE / GX-IE-XL .
●
3.2.18 3.2.19 3.2.20
112 – 117 118 – 121 122 – 125
X-SW Soft Washer
For fastening thin or easily damaged materials to concrete or steel ● ● ● 3.2.18 112 – 117
Ceiling Fastening Systems
For hanging lay-in panel or acoustical suspended ceilings
Reference individual section for tool information .
130 – 138
Grating and Checkerplate Fastening Systems
For fastening grating and checkerplate for marine and industrial environments
Reference individual section for tool information .
139 – 148
Steel Deck Fastening Systems
For fastening steel deck panels to bar joists and structural steel , as well as steel deck panel to panel at the sidelap
Reference individual section for tool information .
149 – 204
Self-Drilling Screw Fasteners
For cold-formed steel connections and gypsum , wood and other materials to cold-formed steel
Reference individual section for tool information .
205 – 232
