Limit States Design ( LSD ) – Factored resistance diaphragm shears , S LSD , ( N / mm ) and stiffness factors , G ’, ( 10 3 N / mm ) for standard 38mm deep flutes , 152mm center-to-center deck ( F y

≥345 Mpa ; F u

≥450 Mpa ) installed with Hilti X-ENP-19 L15 fasteners with 914 / 11 ( 36 / 11 ) or 914 / 9 ( 36 / 9 ) end and interior support fastener patterns 1 , 2 , 3 , 4 , 5 , 6 , 7

Gauge

22

20

18

16

Number of Hilti SLC per span

2

3

4

5

6

7

2

3

4

5

6

7

2

3

4

5

6

7

2

3

4

5

6

7

6 ''

Factor

36 '' 1-1 / 2 ''

6 '' 152 mm 36 ''

714 mm1-1 / 2 ''

S LSD

27.2 23.4 22.4 19.5 18.6 16.4 15.8 13.8 13.7 12.0 12.2 10.5 11.0 9.5 6 ''

G ' 11.6 11.4 12.8 12.4 13.5 13.0 13.9 13.2 14.0

36 '' 13.3 14.1 13.21-1 / 14.0 2 '' 13.1

S LSD

29.6 25.7 24.5 21.5 20.7 18.3 17.6 15.6 15.2 13.5 13.5 11.9 12.2 10.8 G ' 11.8 11.5 12.9 12.6 13.7 13.3 14.2 13.6 14.4 13.7 14.5 13.7 14.4 13.6

S LSD

31.7 27.6 26.4 23.3 22.5 20.0 19.4 17.4 16.8 15.0 14.9 13.4 13.4 12.0 G ' 11.9 11.7 13.1 12.8 13.9 13.5 14.4 13.9 14.7 14.1 14.8 14.1 14.8 14.1

S LSD

33.8 29.6 28.4 25.1 24.2 21.6 21.0 18.9 18.3 16.5 16.2 14.7 14.6 13.2 G ' 12.0 11.8 13.2 13.0 14.1 13.8 14.7 14.2 15.0 14.5 15.1 14.5 15.2 14.5

S LSD

35.9 31.2 30.2 26.7 25.8 23.1 22.7 20.3 19.8 18.2 17.6 16.1 15.8 14.4 G ' 12.0 11.9 13.4 13.1 14.3 14.0 14.9 14.5 15.2 14.8 15.4 14.9 15.5 14.9

S LSD

37.7 32.9 32.0 28.2 27.5 24.6 24.0 21.8 21.3 19.4 18.9 17.4 16.1 15.6 G ' 12.1 12.0 13.5 13.3 14.4 14.1 15.1 14.7 15.5 15.0 15.7 15.2 15.8 15.2

S LSD

35.1 30.5 29.0 25.2 24.3 21.5 20.7 18.2 18.0 15.8 15.8 13.8 14.1 12.5 G ' 16.4 15.9 17.5 16.8 18.0 17.2 18.2 17.2 18.1 17.0 17.9 16.7 17.5 16.2

S LSD

38.4 33.5 32.0 28.1 27.2 24.0 23.3 20.7 20.1 18.0 17.7 15.8 15.9 14.3 G ' 16.6 16.2 17.8 17.2 18.4 17.7 18.7 17.8 18.6 17.7 18.4 17.4 18.1 17.0

S LSD

41.6 36.3 34.7 30.6 29.6 26.3 25.7 23.0 22.4 20.1 19.8 17.9 17.7 15.9 G ' 16.8 16.4 18.1 17.6 18.8 18.1 19.1 18.3 19.1 18.2 19.0 18.0 18.7 17.7

S LSD

44.4 38.9 37.4 33.0 32.0 28.5 27.9 25.1 24.6 22.4 21.8 19.8 19.5 17.7 G ' 17.0 16.7 18.3 17.9 19.1 18.5 19.5 18.8 19.6 18.8 19.5 18.6 19.2 18.3

S LSD

47.1 41.1 39.9 35.3 34.4 30.8 30.0 27.0 26.7 24.2 23.7 21.8 21.3 19.5 G ' 17.1 16.8 18.5 18.1 19.4 18.8 19.8 19.2 20.0 19.2 19.9 19.1 19.7 18.8

S LSD

49.7 43.2 42.3 37.4 36.6 32.7 32.1 29.0 28.5 26.0 25.7 23.4 21.5 21.3 G ' 17.2 17.0 18.7 18.4 19.6 19.2 20.1 19.5 20.3 19.7 20.3 19.6 20.2 19.4

S LSD

42.5 36.8 35.1 30.6 29.7 26.1 25.2 22.2 21.9 19.4 19.4 17.0 17.3 15.2 G ' 25.7 24.7 26.3 25.0 26.2 24.7 25.8 24.1 25.1 23.3 24.3 22.4 23.4 21.5

S LSD

46.5 40.5 38.7 33.9 32.9 29.1 28.4 25.4 24.6 22.1 21.8 19.5 19.5 17.4 G ' 26.1 25.3 26.9 25.8 27.0 25.6 26.6 25.1 26.0 24.3 25.2 23.5 24.4 22.6

S LSD

50.4 44.0 42.0 37.2 36.0 32.0 31.4 28.1 27.5 24.8 24.2 21.9 21.6 19.5 G ' 26.5 25.8 27.4 26.4 27.6 26.4 27.3 26.0 26.8 25.3 26.1 24.5 25.3 23.6

S LSD

54.0 47.1 45.3 40.1 38.9 34.8 34.1 30.6 30.2 27.2 26.7 24.3 23.9 21.8 G ' 26.9 26.2 27.9 27.0 28.2 27.1 28.0 26.8 27.5 26.2 26.9 25.4 26.1 24.6

S LSD

57.3 50.0 48.5 42.9 41.9 37.4 36.6 33.0 32.6 29.4 29.1 26.6 26.0 23.9 G ' 27.2 26.6 28.4 27.6 28.7 27.8 28.6 27.5 28.2 27.0 27.6 26.3 26.9 25.5

S LSD

60.3 52.5 51.5 45.5 44.6 39.9 39.2 35.3 34.8 31.7 31.4 28.5 28.2 26.0 G ' 27.5 27.0 28.8 28.0 29.2 28.3 29.2 28.2 28.9 27.7 28.3 27.1 27.7 26.3

S LSD

43.4 37.7 35.9 31.4 30.5 26.7 26.0 23.0 22.7 20.0 20.0 17.6 17.9 15.8 G ' 35.6 33.9 35.4 33.3 34.4 32.1 33.1 30.7 31.8 29.2 30.3 27.7 29.0 26.3

S LSD

47.7 41.6 39.6 35.0 33.8 29.9 29.4 26.1 25.5 23.0 22.7 20.3 20.3 18.2 G ' 36.4 34.9 36.3 34.5 35.5 33.5 34.4 32.1 33.0 30.7 31.7 29.2 30.3 27.9

S LSD

51.8 45.2 43.4 38.3 37.1 33.0 32.3 29.0 28.5 25.7 25.2 22.8 22.5 20.4 G ' 37.1 35.8 37.2 35.6 36.6 34.7 35.5 33.4 34.2 32.0 32.9 30.6 31.6 29.3

S LSD

55.5 48.5 46.8 41.4 40.2 36.0 35.1 31.7 31.2 28.2 27.8 25.4 24.9 22.8 G ' 37.7 36.6 38.0 36.5 37.5 35.8 36.5 34.6 35.3 33.3 34.0 31.9 32.7 30.6

S LSD

59.0 51.5 50.1 44.4 43.2 38.7 38.0 34.2 33.8 30.6 30.3 27.6 27.3 25.1 G ' 38.3 37.2 38.8 37.4 38.3 36.8 37.4 35.7 36.3 34.5 35.1 33.1 33.8 31.8

S LSD

62.3 54.0 53.3 47.1 46.2 41.4 40.7 36.8 36.2 32.9 32.6 29.7 29.6 27.2 G ' 38.8 37.9 39.4 38.2 39.1 37.7 38.3 36.7 37.3 35.5 36.1 34.3 34.8 33.0

1 Tabulated diaphragm shear values are for attachment of steel deck to a base steel thickness , t f

≥ 6 mm . 2 Tabulated LSD diaphragm shear loads are calculated with a phi factor ( Φ ) of 0.75 for wind loads . To calculate LSD values for load combinations involving earthquake , divide values in table by

0.75 and multiply by a phi factor ( Φ ) of 0.55 . Panel buckling has been checked . 3 Please refer to footnotes 3 through 7 on page 171 .
