3.0 MODULAR SUPPORT SYSTEM 3.1.2 MT BEAM AND COLUMN LOAD TABLES
Modular Support Systems Technical Guide, Edition 1
Table 41- MT-50 Maximum Factored Beam Loads: X-axis Bending 1, 2, 3, 4, 5
Span in( cm)
Max Factored Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
24
3,020
0.09
3,020
3,020
2,190
( 61.0)
( 13,430)
( 0.23)
( 13,430)
( 13,430)
( 9,740)
36
2,010
0.21
1,945
1,460
970
( 91.4)
( 8,940)
( 0.53)
( 8,650)
( 6,490)
( 4,310)
48
1,510
0.37
1,095
820
545
( 121.9)
( 6,715)
( 0.93)
( 4,870)
( 3,645)
( 2,420)
60
1,205
0.57
700
525
350
( 152.4)
( 5,360)
( 1.46)
( 3,110)
( 2,335)
( 1,555)
72
1,005
0.83
485
365
240
( 182.9)
( 4,470)
( 2.10)
( 2,155)
( 1,620)
( 1,065)
84
860
1.13
355
265
175
( 213.4)
( 3,825)
( 2.86)
( 1,575)
( 1,175)
( 775)
96
755
1.47
270
205
135
( 243.8)
( 3,355)
( 3.74)
( 1,200)
( 910)
( 600)
108
670
1.86
215
160
105
( 274.3)
( 2,980)
( 4.73)
( 955)
( 710)
( 465)
120
600
2.30
175
130
85
( 304.8)
( 2,665)
( 5.84)
( 775)
( 575)
( 375)
144
500
3.31
120
90
60
( 365.8)
( 2,220)
( 8.40)
( 530)
( 400)
( 265)
168
430
4.50
85
65
40
( 426.7)
( 1,910)
( 11.44)
( 375)
( 285)
( 175)
192
375
5.88
65
50
30
( 487.7)
( 1,665)
( 14.94)
( 285)
( 220)
( 130)
216
( 548.6)
335
( 1,490)
7.45
( 18.91)
50
( 220)
40
( 175)
-
240
( 609.6)
300
( 1,330)
9.19
( 23.35)
40
( 175)
30
( 130)
-
Table 42- MT-50 Maximum Factored Beam Loads: Y-axis Bending 1, 2, 3, 4, 5
Span in( cm)
Max Factored Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
24
4,270
0.10
4,270
4,270
2,850
( 61.0)
( 18,990)
( 0.25)
( 18,990)
( 18,990)
( 12,675)
36
2,845
0.22
2,535
1,900
1,265
( 91.4)
( 12,655)
( 0.57)
( 11,275)
( 8,450)
( 5,625)
48
2,135
0.40
1,425
1,065
710
( 121.9)
( 9,495)
( 1.01)
( 6,335)
( 4,735)
( 3,155)
60
1,705
0.62
910
680
455
( 152.4)
( 7,580)
( 1.58)
( 4,045)
( 3,020)
( 2,020)
72
1,420
0.90
630
475
315
( 182.9)
( 6,315)
( 2.28)
( 2,800)
( 2,110)
( 1,400)
84
1,220
1.22
465
345
230
( 213.4)
( 5,425)
( 3.10)
( 2,065)
( 1,530)
( 1,020)
96
1,065
1.59
355
265
175
( 243.8)
( 4,735)
( 4.05)
( 1,575)
( 1,175)
( 775)
108
945
2.01
280
210
140
( 274.3)
( 4,200)
( 5.11)
( 1,245)
( 930)
( 620)
120
850
2.48
225
170
110
( 304.8)
( 3,780)
( 6.31)
( 1,000)
( 755)
( 485)
144
710
3.58
155
115
75
( 365.8)
( 3,155)
( 9.10)
( 685)
( 510)
( 330)
168
610
4.89
115
85
55
( 426.7)
( 2,710)
( 12.42)
( 510)
( 375)
( 240)
192
530
6.34
85
65
40
( 487.7)
( 2,355)
( 16.11)
( 375)
( 285)
( 175)
216
470
8.01
70
50
35
( 548.6)
( 2,090)
( 20.34)
( 310)
( 220)
( 155)
240
( 609.6)
425
( 1,890)
9.93
( 25.23)
55
( 240)
40
( 175)
-
Table 43- MT-50 Maximum Factored Column
Loads 1, 2, 6, 7, 8
Unbraced Height in( cm)
Max Factored Load at Channel Face lbs( N)
K = 0.65 lbs( N)
Maximum Column Load Applied at C. G.
K = 0.80 lbs( N)
K = 1.0 lbs( N)
K = 1.2 lbs( N)
24
6,335
15,850
14,655
12,555
10,940
( 61.0)
( 28,185)
( 70,520)
( 65,205)
( 55,855)
( 48,680)
36
4,835
12,765
10,940
8,870
7,190
( 91.4)
( 21,525)
( 56,780)
( 48,680)
( 39,460)
( 31,990)
48
4,130
10,205
8,270
6,305
5,080
( 121.9)
( 18,385)
( 45,415)
( 36,800)
( 28,055)
( 22,610)
60
3,425
8,125
6,305
4,845
3,945
( 152.4)
( 15,245)
( 36,160)
( 28,055)
( 21,550)
( 17,550)
72
2,905
6,500
5,080
3,945
3,200
( 182.9)
( 12,940)
( 28,920)
( 22,610)
( 17,550)
( 14,250)
84
2,520
5,405
4,260
3,310
2,660
( 213.4)
( 11,205)
( 24,050)
( 18,960)
( 14,735)
( 11,845)
96
2,220
4,635
3,660
2,820
2,245
( 243.8)
( 9,895)
( 20,625)
( 16,305)
( 12,550)
( 9,990)
108
( 274.3)
1,970
( 8,770)
4,060
( 18,060)
3,200
( 14,250)
2,440
( 10,855)
**
120
( 304.8)
1,770
( 7,880)
3,600
( 16,015)
2,820
( 12,550)
**
**
144
1,440
2,915
2,245
( 365.8)
( 6,405)
( 12,970)
( 9,990)
**
**
����“)
����
Notes:
1. Loads are based on ICC-ES ELC-5019 and CSA S136-16, the North American Specification for the Design of Cold-Formed Steel Structural Members( using the Appendix B provisions applicable to Canada), CSA Group.
2. Resistance factors for flexure and compression are 0.90 and 0.80, respectively.
3. Maximum factored beam loads in table are given in total uniform load( W * Span) and based on a uniformly loaded condition with simply supported ends. For other loading and support conditions, see page 32 for applicable load and deflection modification factors.
4. Beams spans in table are assumed to be sufficiently laterally braced. Unbraced spans may reduce beam load carrying capacity. See page 49 for reduction factors for unbraced conditions.
5. Profile weight, 1.97 lbs / ft( 28.74 N / m), must be deducted from maximum factored beam load values. 6. C. G. is the‘ Center of Gravity’ of the cross section. 7. ** indicates KL / r for compression exceeds 200. 8. Maximum factored load at channel face assumes K value of 0.8.
����
��������“)
��������“) ��
��������“)
����
��������“) ���
���
�����“)
�����
�����“)
�������
�����“ x �����“)
mm( in)
