3.0 MODULAR SUPPORT SYSTEM 3.1.2 MT BEAM AND COLUMN LOAD TABLES
Modular Support Systems Technical Guide, Edition 1
Table 27- MT-80 Allowable Beam Loads: X-axis Bending 1, 2, 3, 4, 5, 6
Span in( cm)
Max Allowable Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
24
13,920
0.04
13,920
13,920
13,920
( 61.0)
( 61,915)
( 0.09)
( 61,915)
( 61,915)
( 61,915)
36
9,280
0.08
9,280
9,280
9,280
( 91.4)
( 41,275)
( 0.20)
( 41,275)
( 41,275)
( 41,275)
48
6,960
0.14
6,960
6,960
6,505
( 121.9)
( 30,955)
( 0.36)
( 30,955)
( 30,955)
( 28,935)
60
5,565
0.22
5,565
5,565
4,165
( 152.4)
( 24,750)
( 0.57)
( 24,750)
( 24,750)
( 18,525)
72
4,640
0.32
4,640
4,335
2,890
( 182.9)
( 20,635)
( 0.81)
( 20,635)
( 19,280)
( 12,855)
84
3,975
0.44
3,975
3,185
2,125
( 213.4)
( 17,680)
( 1.11)
( 17,680)
( 14,165)
( 9,450)
96
3,480
0.57
3,250
2,440
1,625
( 243.8)
( 15,475)
( 1.45)
( 14,455)
( 10,850)
( 7,225)
108
3,095
0.72
2,570
1,925
1,285
( 274.3)
( 13,765)
( 1.83)
( 11,430)
( 8,560)
( 5,715)
120
2,780
0.89
2,080
1,560
1,040
( 304.8)
( 12,365)
( 2.26)
( 9,250)
( 6,935)
( 4,625)
144
2,320
1.28
1,445
1,080
720
( 365.8)
( 10,315)
( 3.26)
( 6,425)
( 4,800)
( 3,200)
168
1,985
1.74
1,060
795
530
( 426.7)
( 8,825)
( 4.43)
( 4,715)
( 3,535)
( 2,355)
192
1,740
2.28
810
610
405
( 487.7)
( 7,735)
( 5.79)
( 3,600)
( 2,710)
( 1,800)
216
1,545
2.88
640
480
320
( 548.6)
( 6,870)
( 7.32)
( 2,845)
( 2,135)
( 1,420)
240
1,390
3.56
520
390
260
( 609.6)
( 6,180)
( 9.04)
( 2,310)
( 1,730)
( 1,155)
Table 28- MT-80 Allowable Beam Loads: Y-axis Bending 1, 2, 3, 4, 5, 6
Span in( cm)
Max Allowable Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
24
7,000
0.02
7,000
7,000
7,000
( 61.0)
( 31,135)
( 0.05)
( 31,135)
( 31,135)
( 31,135)
36
4,665
0.04
4,665
4,665
3,130
( 91.4)
( 20,750)
( 0.10)
( 20,750)
( 20,750)
( 13,920)
48
3,500
0.07
3,500
2,640
1,760
( 121.9)
( 15,565)
( 0.18)
( 15,565)
( 11,740)
( 7,825)
60
2,800
0.11
2,255
1,690
1,125
( 152.4)
( 12,450)
( 0.28)
( 10,030)
( 7,515)
( 5,000)
72
2,330
0.16
1,565
1,170
780
( 182.9)
( 10,360)
( 0.41)
( 6,960)
( 5,200)
( 3,465)
84
2,000
0.22
1,150
860
575
( 213.4)
( 8,895)
( 0.56)
( 5,115)
( 3,825)
( 2,555)
96
1,750
0.29
880
660
440
( 243.8)
( 7,780)
( 0.73)
( 3,910)
( 2,935)
( 1,955)
108
1,555
0.36
695
520
345
( 274.3)
( 6,915)
( 0.92)
( 3,090)
( 2,310)
( 1,530)
120
1,400
0.45
560
420
280
( 304.8)
( 6,225)
( 1.14)
( 2,490)
( 1,865)
( 1,245)
144
1,165
0.64
390
290
195
( 365.8)
( 5,180)
( 1.64)
( 1,730)
( 1,285)
( 865)
168
1,000
0.88
285
215
140
( 426.7)
( 4,445)
( 2.23)
( 1,265)
( 955)
( 620)
192
875
1.15
220
165
110
( 487.7)
( 3,890)
( 2.91)
( 975)
( 730)
( 485)
216
( 548.6)
775
( 3,445)
1.45
( 3.67)
170
( 755)
130
( 575)
-
240
( 609.6)
700
( 3,110)
1.79
( 4.55)
140
( 620)
-
-
Table 29- MT-80 Allowable Column Loads 1, 2, 6, 7, 8, 9
Unbraced Height in( cm)
Max Allowable Load at Girder Face lbs( N)
K = 0.65 lbs( N)
Maximum Column Load Applied at C. G.
K = 0.80 lbs( N)
K = 1.0 lbs( N)
K = 1.2 lbs( N)
24
11,820
29,775
29,775
29,775
29,775
( 61.0)
( 52,575)
( 132,445)
( 132,445)
( 132,445)
( 132,445)
36
11,540
29,775
29,775
29,775
29,200
( 91.4)
( 51,330)
( 132,445)
( 132,445)
( 132,445)
( 129,885)
48
11,160
29,775
29,775
27,665
23,755
( 121.9)
( 49,640)
( 132,445)
( 132,445)
( 123,055)
( 105,665)
60
10,430
29,775
27,665
22,890
18,585
( 152.4)
( 46,390)
( 132,445)
( 123,055)
( 101,815)
( 82,665)
72
8,590
28,060
23,755
18,585
13,740
( 182.9)
( 38,210)
( 124,815)
( 105,665)
( 82,665)
( 61,115)
84
7,770
24,830
20,295
14,530
10,095
( 213.4)
( 34,560)
( 110,445)
( 90,275)
( 64,630)
( 44,900)
96
6,960
22,025
16,920
11,130
7,730
( 243.8)
( 30,955)
( 97,970)
( 75,260)
( 49,505)
( 34,380)
108
6,160
19,220
13,740
8,795
6,105
( 274.3)
( 27,400)
( 85,490)
( 61,115)
( 39,120)
( 27,155)
120
5,440
16,510
11,130
7,120
4,945
( 304.8)
( 24,195)
( 73,435)
( 49,505)
( 31,670)
( 21,995)
144
( 365.8)
4,300
( 19,125)
11,710
( 52,085)
7,730
( 34,380)
4,945
( 21,995)
**
Notes: 1. Loads are based on ICC-ES ESR-5019 and AISI S100-16, the North American
Specification for the Design of Cold-Formed Steel Structural Members. 2. Safety factors for flexure and compression are 1.67 and 1.80, respectively. 3. Allowable beam loads in table are given in total uniform load( W * Span) and based on a uniformly loaded condition with simply supported ends. For other loading and support conditions, see page 32 for applicable load and deflection modification factors.
4. Beams spans in table are assumed to be sufficiently laterally braced. Unbraced spans may reduce beam load carrying capacity. See page 49 for reduction factors for unbraced conditions.
5. Profile weight, 4.43 lbs / ft( 64.67 N / m), must be deducted from allowable beam load values.
6. Multiply tabulated load values by 1.5 to obtain Load and Resistance Factor
Design( LRFD) values. 7. C. G. is the‘ Center of Gravity’ of the cross section. 8. ** indicates KL / r for compression exceeds 200. 9. Maximum allowable load at girder face assumes K value of 0.8.
