3.0 MODULAR SUPPORT SYSTEM 3.1.2 MT BEAM AND COLUMN LOAD TABLES
Modular Support Systems Technical Guide, Edition 1
Table 22- MT-60 Allowable Beam Loads: X-axis Bending 1, 2, 3, 4, 5, 6
Span in( cm)
Max Allowable Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
24
4,135
0.03
4,135
4,135
4,135
( 61.0)
( 18,390)
( 0.08)
( 18,390)
( 18,390)
( 18,390)
36
2,755
0.07
2,755
2,755
2,755
( 91.4)
( 12,250)
( 0.18)
( 12,250)
( 12,250)
( 12,250)
48
2,065
0.13
2,065
2,065
2,065
( 121.9)
( 9,185)
( 0.33)
( 9,185)
( 9,185)
( 9,185)
60
1,650
0.20
1,650
1,650
1,360
( 152.4)
( 7,335)
( 0.51)
( 7,335)
( 7,335)
( 6,045)
72
1,375
0.29
1,375
1,375
945
( 182.9)
( 6,115)
( 0.74)
( 6,115)
( 6,115)
( 4,200)
84
1,180
0.40
1,180
1,040
695
( 213.4)
( 5,245)
( 1.01)
( 5,245)
( 4,625)
( 3,090)
96
1,030
0.52
1,030
795
530
( 243.8)
( 4,580)
( 1.31)
( 4,580)
( 3,535)
( 2,355)
108
915
0.65
840
630
420
( 274.3)
( 4,070)
( 1.66)
( 3,735)
( 2,800)
( 1,865)
120
825
0.81
680
510
340
( 304.8)
( 3,665)
( 2.05)
( 3,020)
( 2,265)
( 1,510)
144
685
1.16
470
355
235
( 365.8)
( 3,045)
( 2.96)
( 2,090)
( 1,575)
( 1,045)
168
590
1.58
345
260
170
( 426.7)
( 2,620)
( 4.02)
( 1,530)
( 1,155)
( 755)
192
515
2.07
265
195
130
( 487.7)
( 2,290)
( 5.26)
( 1,175)
( 865)
( 575)
216
455
2.62
210
155
105
( 548.6)
( 2,020)
( 6.65)
( 930)
( 685)
( 465)
240
410
3.23
170
125
85
( 609.6)
( 1,820)
( 8.21)
( 755)
( 555)
( 375)
Table 23- MT-60 Allowable Beam Loads: Y-axis Bending 1, 2, 3, 4, 5, 6
Span in( cm)
Max Allowable Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
24
3,960
0.06
3,960
3,960
3,960
( 61.0)
( 17,610)
( 0.15)
( 17,610)
( 17,610)
( 17,610)
36
2,640
0.13
2,640
2,640
2,015
( 91.4)
( 11,740)
( 0.33)
( 11,740)
( 11,740)
( 8,960)
48
1,980
0.23
1,980
1,700
1,130
( 121.9)
( 8,805)
( 0.59)
( 8,805)
( 7,560)
( 5,025)
60
1,580
0.36
1,450
1,085
725
( 152.4)
( 7,025)
( 0.92)
( 6,445)
( 4,825)
( 3,220)
72
1,320
0.52
1,005
755
500
( 182.9)
( 5,870)
( 1.33)
( 4,470)
( 3,355)
( 2,220)
84
1,130
0.71
740
555
370
( 213.4)
( 5,025)
( 1.81)
( 3,290)
( 2,465)
( 1,645)
96
990
0.93
565
425
280
( 243.8)
( 4,400)
( 2.36)
( 2,510)
( 1,890)
( 1,245)
108
880
1.18
445
335
220
( 274.3)
( 3,910)
( 2.99)
( 1,975)
( 1,490)
( 975)
120
790
1.45
360
270
180
( 304.8)
( 3,510)
( 3.69)
( 1,600)
( 1,200)
( 800)
144
660
2.09
250
185
125
( 365.8)
( 2,935)
( 5.32)
( 1,110)
( 820)
( 555)
168
565
2.85
185
135
90
( 426.7)
( 2,510)
( 7.24)
( 820)
( 600)
( 400)
192
495
3.72
140
105
70
( 487.7)
( 2,200)
( 9.46)
( 620)
( 465)
( 310)
216
440
4.71
110
80
55
( 548.6)
( 1,955)
( 11.97)
( 485)
( 355)
( 240)
240
395
5.82
90
65
45
( 609.6)
( 1,755)
( 14.78)
( 400)
( 285)
( 200)
Table 24- MT-60 Allowable Column Loads 1, 2, 6, 7, 8, 9
Unbraced Height in( cm)
2023
Max Allowable Load at Channel Face lbs( N)
K = 0.65 lbs( N)
Maximum Column Load Applied at C. G.
K = 0.80 lbs( N)
K = 1.0 lbs( N)
K = 1.2 lbs( N)
24
5,340
15,420
14,005
12,045
10,145
( 61.0)
( 23,750)
( 68,590)
( 62,295)
( 53,575)
( 45,125)
36
4,630
12,290
10,145
7,630
5,725
( 91.4)
( 20,595)
( 54,665)
( 45,125)
( 33,935)
( 25,465)
48
3,690
9,255
6,890
4,885
3,780
( 121.9)
( 16,410)
( 41,165)
( 30,645)
( 21,725)
( 16,810)
60
2,865
6,720
4,885
3,580
2,845
( 152.4)
( 12,740)
( 29,890)
( 21,725)
( 15,920)
( 12,655)
72
2,325
5,070
3,780
2,845
2,305
( 182.9)
( 10,340)
( 22,550)
( 16,810)
( 12,655)
( 10,250)
84
1,940
4,065
3,095
2,375
1,945
( 213.4)
( 8,625)
( 18,080)
( 13,765)
( 10,560)
( 8,650)
96
1,660
3,400
2,635
2,050
1,690
( 243.8)
( 7,380)
( 15,120)
( 11,720)
( 9,115)
( 7,515)
108
1,460
2,935
2,305
1,810
1,490
( 274.3)
( 6,490)
( 13,055)
( 10,250)
( 8,050)
( 6,625)
120
( 304.8)
1,310
( 5,825)
2,590
( 11,520)
2,050
( 9,115)
1,615
( 7,180)
**
144
( 365.8)
1,090
( 4,845)
2,110
( 9,385)
1,690
( 7,515)
**
**
Notes: 1. Loads are based on ICC-ES ESR-5019 and AISI S100-16, the North American
Specification for the Design of Cold-Formed Steel Structural Members. 2. Safety factors for flexure and compression are 1.67 and 1.80, respectively. 3. Allowable beam loads in table are given in total uniform load( W * Span) and based on a uniformly loaded condition with simply supported ends. For other loading and support conditions, see page 32 for applicable load and deflection modification factors.
4. Beams spans in table are assumed to be sufficiently laterally braced. Unbraced spans may reduce beam load carrying capacity. See page 49 for reduction factors for unbraced conditions.
5. Profile weight, 2.83 lbs / ft( 41.30 N / m), must be deducted from allowable beam load values.
6. Multiply tabulated load values by 1.5 to obtain Load and Resistance Factor
Design( LRFD) values. 7. C. G. is the‘ Center of Gravity’ of the cross section. 8. ** indicates KL / r for compression exceeds 200. 9. Maximum allowable load at channel face assumes K value of 0.8.
�� ��������“)
����“) ����
����“) ����
��������“)
��������“) �� ����
��������“) ���
�������
